Brewsterite-Ba

Ba(Al2Si6)O16 · 5H2O
IMA status
  • Approved
IMA symbol
Brw-Ba
Also known as
  • Barium-Brewsterite

Where it forms, where it's found

Geological setting

In fractures in radiolaritic metacherts and in a schistose metapelite above radiolaritic strata (Italy). In cavities in prehnite in a wollastonite orebody, probably formed by hydrothermal mineralization along fractures (New York).

Type locality
Cerchiara Mine
  1. Borghetto di Vara
  2. La Spezia Province
  3. Liguria
  4. Italy

44.1983°, 9.7075°

10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
White · colorless · pale pink
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (010).

Fracture
Conchoidal
Density
2.50 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 44 – 45° · 2V calc = 46 – 48°
Refractive index
1.512 – 1.53
Surface relief
Moderate
Principal indices
nα 1.512 – 1.516 · nβ 1.514 – 1.518 · nγ 1.526 – 1.530
Extinction
X ∧ c = 36° (in β obtuse); Z = b.
UV response
Material from New York fluoresces bright yellow-green in shortwave ultraviolet light.
Notes

Robinson and Grice give 2Vmeas = 57(5)°, 2Vcalc = 64(10)°. Cabella et al. give 2Vmeas = 45(1)°, 2Vcalc = 44°.

Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 6.790(1) Å · b = 17.581(4) Å · c = 7.735(1) Å
Cell angles
β = 94.50(3) °
Ratio a:b:c
1 : 2.589 : 1.139
Morphology

Prismatic crystals. Also platy aggregates of flattened, pinacoidal crystals. Crystal tabular on (010) and showing the forms (001), (010) and (001).

Twinning

Lamellar parallel to (010).

Type-locality form

Prismatic crystals to 0.2 mm long and as radiating and parallel aggregates (Italy). Platy aggregates of flattened, pinacoidal crystals up to 1 mm across (New York).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
47.60%
14SiSiliconSilicon628.085168.510
23.87%
56BaBariumBarium1137.327137.327
19.46%
13AlAluminiumAluminium226.98253.964
7.64%
1HHydrogenHydrogen101.00810.080
1.43%
Total705.860100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Barium-Brewsterite

In other languages

German
Brewsterit-Ba
Italian
brewsterite-Ba

Classification

Strunz
10th ed.

9.GE.20

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GEChains of T10O20 TetrahedraGroup
  • 9.GE.20Brewsterite-BaSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1993Robinson, G.W. & Grice, J.D. (1993): The barium analog of brewsterite from Harrisville, New York. Canadian Mineralogist, 31, 676-690.
  2. 1993Cabella, Roberto, Lucchetti, Gabriella, Palenzona, Andrea, Quartieri, Simona, Vezzalini, Glovanna (1993) First occurrence of a Ba-dominant brewsterite: structural features. European Journal of Mineralogy, 5 (2) 353-360 doi:10.1127/ejm/5/2/0353DOI: 10.1127/ejm/5/2/0353
  3. 1997Coombs, Douglas S., Alberti, Alberto, Armbruster, Thomas, Artioli, Gilberto, Colella, Carmine, Galli, Ermanno, Grice, Joel D., Liebau, Friedrich, Mandarino, Joseph A., Minato, Hideo, et al. (1997) Recommended nomenclature for zeolite minerals; report of the Subcommittee on Zeolites of the International Mineralogical Association, Commission on New Minerals and Mineral Names. The Canadian Mineralogist, 35 (6). 1571-1606
  4. 1999Alberti, A.; Sacerdoti, M.; Quartieri, S.; Vezzalini, G. (1999) Heating-induced phase transformation in zeolite brewsterite: new 4- and 5-coordinated (Si,Al) sites. Physics and Chemistry of Minerals, 26 (3). 181-186 doi:10.1007/s002690050175DOI: 10.1007/s002690050175
  5. 2000Sacerdoti, Michele, Vezzalini, Giovanna, Quartieri, Simona (2000) Dehydration mechanism in brewsterite: single-crystal X-ray diffraction study. Microporous and Mesoporous Materials, 41 (1-3). 107-118 doi:10.1016/s1387-1811(00)00278-xDOI: 10.1016/s1387-1811(00)00278-x
