Brewsterite-Sr

Sr(Al2Si6)O16 · 5H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Brw-Sr

Where it forms, where it's found

Geological setting

Epithermal veins.

Type locality
Strontian
  1. Fort William and Ardnamurchan
  2. Highland
  3. Scotland
  4. UK

56.6960°, -5.5690°

10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colorless · white
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (010).

Fracture
Irregular/Uneven
Density
2.45 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 65°
Refractive index
1.51 – 1.523
Surface relief
Moderate
Principal indices
nα 1.51 · nβ 1.512 · nγ 1.523
Dispersion
none
Extinction
Z = b; X ∧ c = 19°-34° (in various sectors).
Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 6.77 Å · b = 17.51 Å · c = 7.74 Å
Cell angles
β = 94.3 °
Ratio a:b:c
1 : 2.586 : 1.143
Morphology

Prismatic crystals.

Twinning

Lamellar parallel to (010).

Type-locality form

Prismatic crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
51.21%
14SiSiliconSilicon628.085168.510
25.68%
38SrStrontiumStrontium187.62087.620
13.35%
13AlAluminiumAluminium226.98253.964
8.22%
1HHydrogenHydrogen101.00810.080
1.54%
Total656.153100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

German
Brewsterit-Sr
Italian
brewsterite-Sr
Chinese
锶沸石

Classification

Strunz
10th ed.

9.GE.20

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GEChains of T10O20 TetrahedraGroup
  • 9.GE.20Brewsterite-SrSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1822Brooke, H.J. (1822) On the comptonite of Vesuvius, the brewsterite of Scotland, the stilbite and the heulandite. Edinburgh Philosophical Journal: 6: 112-115.
  2. 1859Mallet, J.W. (1859) XXXIII. On Brewsterite. The London, Edinburgh, and Dublin Philosophical Magazine and Journal of Science: 18(119): 218-220.
  3. 1874De Cloizeau, A. (1874) Manual de mineralogie. Dunod, Editeur, Paris: 420-422.
  4. 1956Strunz, H., Tennyson, C. (1956) "Polymorphie" in der Gruppe der Blätterzeolithe (Heulandit-Stilbit-Epistilbit: Brewsterit). Neues Jahrbuch für Mineralogie - Monatshefte, 11, 1-9.
  5. 1964Perrotta, A. J.; Smith, J. V. (1964) The crystal structure of brewsterite, (Sr, Ba, Ca)(Al2Si6O16).5H2O. Acta Crystallographica, 17 (7). 857-862 doi:10.1107/s0365110x64002298DOI: 10.1107/s0365110x64002298
