Buttgenbachite

Cu36(NO3)2Cl8(OH)62 · nH2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bba
Discovered
1925
Also known as
  • Buttgenbachiet
  • buttgenbackite

Where it forms, where it's found

Type locality
Likasi Mine
  1. Likasi
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0042°, 26.7428°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Deep blue · blue in transmitted light.
Streak
Light blue

Optical

Optical type
Uniaxial (+)
Refractive index
1.738 – 1.752
Surface relief
High
Principal indices
nω 1.738 · nε 1.752
Pleochroism
Non-pleochroic
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 15.75 Å · c = 9.161 Å
Unit cell volume
1968.04 ų
Z
1
Morphology

Crystals acicular [0001] and striated [0001]; radiating groups of needles; felted aggregates.

Crystal structure

Synonyms

  • Buttgenbachiet
  • buttgenbackite

In other languages

German
Buttgenbachit
Italian
Buttgenbachite
Chinese
毛青铜矿

Classification

Strunz
10th ed.

3.DA.25

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DAWith Cu, etc., without PbGroup
  • 3.DA.25ButtgenbachiteSpecies
Dana
8th ed.

19.01.02.01

  • 19Nitrates Containing Hydroxyl or HalogenClass
  • 19.01Anhydrous Nitrates Containing Hydroxyl or HalogenType
  • 19.01.02— unnamed intermediate level —Group
  • 19.01.02.01ButtgenbachiteSpecies
CIM

13.7

  • 13NitratesClass
  • 13.7— unnamed intermediate level —Group
  • 13.7ButtgenbachiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1890Penfield (1890) American Journal of Science: 40: 82.
  2. 1925Schoep, A. (1925) Sur la buttgenbachite, nouveau minéral. Comptes Rendus Hebdomadaires des Séances de l'Académie des Sciences, 181, 421-423.
  3. 1925Schoep, A. (1925) Bulletin de la Société Chimique de Belgique, vol. 34, 313.
  4. 1926Foshag, W.F. (1926) New mineral names. American Mineralogist, 11, 216-220.
  5. 1927Foshag, W.F. (1927) New Mineral Names. American Mineralogist, 12 (10). 379-380
