Calcurmolite

(Ca1-xNax)2(UO2)3(MoO4)2(OH)6-x · nH2O
IMA status
  • Approved
IMA symbol
Cau
Also known as
  • Calcurmoliet

Where it forms, where it's found

Geological setting

A secondary mineral in the lower oxidized zone of Mo–U deposits.

Type locality
Sokh-Karasu area
  1. Kapan
  2. Syunik Province
  3. Armenia
6recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
bright yellow

Optical

Optical type
Biaxial (-) · 2V calc = 76°
Refractive index
1.77 – 1.863
Surface relief
Very high
Principal indices
nα 1.77 · nβ 1.816 – 1.827 · nγ 1.858 – 1.863
Pleochroism
Visible

X = colorless; Y = pale yellow; Z = yellow

Dispersion
r > v distinct
UV response
Strong yellowish green
Michel-Lévy diagramhighlighted lineδ = 0.0905
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]905 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation905 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 16.30(3) Å · b = 25.49(5) Å · c = 19.50(6) Å
Cell angles
β = 90.07 °
Ratio a:b:c
1 : 1.564 : 1.196
Comment

Crystal Data: n.d. Point Group: n.d. Space Group: n.d. Z = n.d.

Synonyms

  • Calcurmoliet

In other languages

German
Calcurmolit
Italian
Calcurmolite

Classification

Strunz
10th ed.

7.HB.15

  • 7SulfatesClass
  • 7.HUranium and uranyl molybdates and wolframatesDivision
  • 7.HBWith U6+Group
  • 7.HB.15CalcurmoliteSpecies
Dana
8th ed.

49.03.01.01

  • 49Hydrated Molybdates and TungstatesClass
  • 49.03Hydrated Molybdates and Tungstates Containing Hydroxyl or HalogenType
  • 49.03.01Calcurmolite GroupGroup
  • 49.03.01.01CalcurmoliteSpecies
CIM

27.3.11

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.3MolybdatesGroup
  • 27.3.11CalcurmoliteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1958Proceedings of the Second UN International Conference on the Peaceful Uses of Atomic Energy, Genève (1958): 3: 160-161.
  2. 1959Rudnitskaya, L.S. (1959) Calcium molybdate of uranium. Yadernoe Goryuchee i Reaktornye Metally: 3: 160-161.
  3. 1963Fedorov, O.V. (1963) The second finding of the calcium molybdate of uranium in the USSR. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 92: 464-465.
  4. 1964Fleischer, M. (1964) New Mineral Names. American Mineralogist, 49 (7-8) 1151-1154
  5. 1992Deliens, M. (1992) Etude comparative des calcurmolites de Rabejac (Lodeve, Hérault, France) et de l'Union Soviétique. Annales de la Société géologique de Belgique: 115(1): 91-97.
