Carlosruizite

K3Na2Na3Mg5(IO3)6(SeO4)6 · 6H2O
IMA status
  • Approved
IMA symbol
Crz
Discovered
1994
Also known as
  • Carlosruiziet
  • IMA1993-020

Where it forms, where it's found

Geological setting

"Caliche amarillo" (yellow nitrate ore) leachate.

Type locality
Zapiga deposit
  1. Iquique
  2. Iquique Province
  3. Tarapacá
  4. Chile

-20.2425°, -70.1350°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless to pale yellow.
Cleavage

possible (fractures || (1120) observed)

Density
3.400 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.642 – 1.655
Surface relief
Moderate
Principal indices
nω 1.655 · nε 1.642
Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
P-3c1
Cell parameters
a = 9.5901(8) Å · c = 27.56(2) Å
Z
1
Morphology

Thin hexagonal plates. (0001) form, beveled by (1012).

Type-locality form

Thin hexagonal plates up to 0.2 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4815.999767.952
32.42%
53IIodineIodine6126.904761.424
32.14%
34SeSeleniumSelenium678.971473.826
20.00%
12MgMagnesiumMagnesium524.305121.525
5.13%
19KPotassiumPotassium339.098117.294
4.95%
11NaSodiumSodium522.990114.950
4.85%
1HHydrogenHydrogen121.00812.096
0.51%
Total2369.067100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Carlosruiziet
  • IMA1993-020

In other languages

German
Carlosruizit · IMA 1993-020
Italian
Carlosruizite
Chinese
卡洛斯鲁伊兹石

Classification

Strunz
10th ed.

7.DG.40

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DGWith large and medium-sized cations; with NO3, CO3, B(OH)4, SiO4 or IO3Group
  • 7.DG.40CarlosruiziteSpecies
Dana
8th ed.

23.01.02.02

  • 23Compound IodatesClass
  • 23.01MiscellaneousType
  • 23.01.02Fuenzalidaite GroupGroup
  • 23.01.02.02CarlosruiziteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1994Konnert, Judith A., Evans, Howard T., Jr.,, Mcgee, James J., Ericksen, George E. (1994) Mineralogical studies of the nitrate deposits of Chile: VII. Two new saline minerals with the composition K6(Na,K)4Na6Mg10(XO4)12(IO3)12 · 12H2O: Fuenzalidaite (X = S) and carlosruizite (X = Se) American Mineralogist, 79 (9-10) 1003-1008
  2. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  3. 2005(2005) Carlosruizite. Handbook of Mineralogy. Mineralogical Society of America
