Fuenzalidaite

K3Na5Mg5(IO3)6(SO4)6 · 6H2O
IMA status
  • Approved
IMA symbol
Fzl
Discovered
1994
Also known as
  • Fuenzalidaiet
  • IMA1993-021

Where it forms, where it's found

Geological setting

Veins and veinlets of "caliche blanco".

Type locality
Oficina Santa Luisa
  1. Canchas
  2. Antofagasta Province
  3. Antofagasta
  4. Chile
2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless to pale yellow
Tenacity
brittle
Cleavage

possible: fractures || (1120) were observed

Optical

Optical type
Uniaxial (-)
Refractive index
1.615 – 1.622
Surface relief
Moderate
Principal indices
nω 1.622 · nε 1.615
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#96
Cell parameters
a = 9.4643(4) Å · c = 27.336(6) Å
Morphology

Crystals are platy with a hexagonal outline. They are pseudorhombohedral, flattened on (0001) with beveled edges (1012).

Type-locality form

Thin, euhedral, platy crystals with hexagonal outline, usually less than 200 microns in diameter and 20 microns thick.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4815.999767.952
36.79%
53IIodineIodine6126.904761.424
36.47%
16SSulfurSulfur632.060192.360
9.21%
12MgMagnesiumMagnesium524.305121.525
5.82%
19KPotassiumPotassium339.098117.294
5.62%
11NaSodiumSodium522.990114.950
5.51%
1HHydrogenHydrogen121.00812.096
0.58%
Total2087.601100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fuenzalidaiet
  • IMA1993-021

In other languages

German
Fuenzalidait · IMA 1993-021
Italian
Fuenzalidaite

Classification

Strunz
10th ed.

7.DG.40

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DGWith large and medium-sized cations; with NO3, CO3, B(OH)4, SiO4 or IO3Group
  • 7.DG.40FuenzalidaiteSpecies
Dana
8th ed.

23.01.02.01

  • 23Compound IodatesClass
  • 23.01MiscellaneousType
  • 23.01.02Fuenzalidaite GroupGroup
  • 23.01.02.01FuenzalidaiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1994Konnert, Judith A., Evans, Howard T., Jr.,, Mcgee, James J., Ericksen, George E. (1994) Mineralogical studies of the nitrate deposits of Chile: VII. Two new saline minerals with the composition K6(Na,K)4Na6Mg10(XO4)12(IO3)12 · 12H2O: Fuenzalidaite (X = S) and carlosruizite (X = Se) American Mineralogist, 79 (9-10) 1003-1008
  2. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (3) 201-204
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2005(2005) Fuenzalidaite. Handbook of Mineralogy. Mineralogical Society of America
