Cesiodymite

CsKCu5O(SO4)5
IMA status
  • Approved
IMA symbol
Ced
IMA approved
2016
Also known as
  • Cäsiodymit
  • Cesiodymiet
  • IMA2016-002

Where it forms, where it's found

Geological setting

Fumarole

Type locality
Arsenatnaya fumarole
  1. Second scoria cone
  2. Northern Breakthrough (North Breach)
  3. Great Fissure eruption (Main Fracture)
  4. Tolbachik Volcanic field
  5. Milkovsky District
  6. Kamchatka Krai
  7. Russia

55.6833°, 160.2333°

1recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Light green to green
Tenacity
brittle
Density
3.59 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70°
Refractive index
1.61 – 1.635
Surface relief
Moderate
Principal indices
nα 1.61 · nβ 1.627 · nγ 1.635
Michel-Lévy diagramhighlighted lineδ = 0.0250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]250 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation250 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 10.0682(4) Å · b = 12.7860(7) Å · c = 14.5486(8) Å
Cell angles
α = 102.038(5) ° · β = 100.847(4) ° · γ = 89.956(4) °
Ratio a:b:c
1 : 1.270 : 1.445
Morphology

Coarse tabular or prismatic crystals; grains up to 0.3 mm

Type-locality form

Coarse tabular or prismatic crystals or grains up to 0.3 mm

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
34.07%
29CuCopperCopper563.546317.730
32.22%
16SSulfurSulfur532.060160.300
16.26%
55CsCaesiumCaesium1132.905132.905
13.48%
19KPotassiumPotassium139.09839.098
3.97%
Total986.012100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cäsiodymit
  • Cesiodymiet
  • IMA2016-002

In other languages

German
Cesiodymit · IMA 2016-002

Classification

Strunz
10th ed.

8.BF.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BFWith medium-sized and large cations, (OH, etc.):RO4< 0.5:1Group
  • 8.BF.35CesiodymiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2016Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2016) New minerals and nomenclature modifications approved in 2016, CNMNC Newsletter no 31. Mineralogical Magazine, 80 (4) 691-697 doi:10.1180/minmag.2016.080.083DOI: 10.1180/minmag.2016.080.083
  2. 2018Pekov, Igor V., Zubkova, Natalia V., Agakhanov, Atali A., Pushcharovsky, Dmitry Y., Yapaskurt, Vasiliy O., Belakovskiy, Dmitry I., Vigasina, Marina F., Sidorov, Evgeny G., Britvin, Sergey N. (2018) Cryptochalcite, K2Cu5O(SO4)5, and cesiodymite, CsKCu5O(SO4)5, two new isotypic minerals and the K–Cs isomorphism in this solid-solution series. European Journal of Mineralogy, 30 (3) 593-607 doi:10.1127/ejm/2018/0030-2725 DOI: 10.1127/ejm/2018/0030-2725
  3. 2020(2020) Cesiodymite. Handbook of Mineralogy. Mineralogical Society of America
