Cryptochalcite

K2Cu5O(SO4)5
IMA status
  • Approved
IMA symbol
Cpch
IMA approved
2015
Also known as
  • Cryptochalciet
  • IMA2014-106

Where it forms, where it's found

Geological setting

Fumarole

Type locality
Arsenatnaya fumarole
  1. Second scoria cone
  2. Northern Breakthrough (North Breach)
  3. Great Fissure eruption (Main Fracture)
  4. Tolbachik Volcanic field
  5. Milkovsky District
  6. Kamchatka Krai
  7. Russia

55.6833°, 160.2333°

1recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Light green to green
Tenacity
brittle
Density
3.41 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 65°
Refractive index
1.61 – 1.643
Surface relief
Moderate
Principal indices
nα 1.610 · nβ 1.632 · nγ 1.643
Michel-Lévy diagramhighlighted lineδ = 0.0330
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]330 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation330 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 10.0045(3) Å · b = 12.6663(4) Å · c = 14.4397(5) Å
Cell angles
α = 102.194(3) ° · β = 102.194(3) ° · γ = 90.008(3) °
Ratio a:b:c
1 : 1.266 : 1.443
Unit cell volume
1751.7 ų
Z
4
Morphology

Coarse tabular or prismatic crystals; grains up to 0.3 mm.

Type-locality form

Coarse tabular or prismatic crystals or grains up to 0.3 mm

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
37.66%
29CuCopperCopper563.546317.730
35.61%
16SSulfurSulfur532.060160.300
17.97%
19KPotassiumPotassium239.09878.196
8.76%
Total892.205100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cryptochalciet
  • IMA2014-106

In other languages

German
Cryptochalcit · IMA 2014-106 · Kryptochalcit
Italian
cryptochalcite

Classification

Strunz
10th ed.

8.BF.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BFWith medium-sized and large cations, (OH, etc.):RO4< 0.5:1Group
  • 8.BF.35CryptochalciteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter No 25. Mineralogical Magazine, 79 (3) 529-535 doi:10.1180/minmag.2015.079.3.02DOI: 10.1180/minmag.2015.079.3.02
  2. 2018Pekov, Igor V., Zubkova, Natalia V., Agakhanov, Atali A., Pushcharovsky, Dmitry Y., Yapaskurt, Vasiliy O., Belakovskiy, Dmitry I., Vigasina, Marina F., Sidorov, Evgeny G., Britvin, Sergey N. (2018) Cryptochalcite, K2Cu5O(SO4)5, and cesiodymite, CsKCu5O(SO4)5, two new isotypic minerals and the K–Cs isomorphism in this solid-solution series. European Journal of Mineralogy, 30 (3) 593-607 doi:10.1127/ejm/2018/0030-2725 DOI: 10.1127/ejm/2018/0030-2725
  3. 2020(2020) Cryptochalcite. Handbook of Mineralogy. Mineralogical Society of America
