Chkalovite

Na2BeSi2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ckl
Discovered
1938

Where it forms, where it's found

Geological setting

In ussingite veinlets in a pegmatite in an alkalic massif.

Type locality
Malyi Punkaruaiv Mountain
  1. Lovozersky District
  2. Murmansk Oblast
  3. Russia

67.7629°, 34.9806°

14recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White
Streak
White
Tenacity
brittle
Cleavage
Imperfect/Fair

Fair in one direction, indistinct in two other directions

Fracture
Irregular/Uneven · Conchoidal
Density
2.662 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 78° · 2V calc = 80°
Refractive index
1.544 – 1.549
Surface relief
Moderate
Principal indices
nα 1.544 · nβ 1.546 · nγ 1.549
Dispersion
noticable
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#23
Cell parameters
a = 21.129 Å · b = 6.881 Å · c = 21.185 Å
Ratio a:b:c
1 : 0.326 : 1.003
Z
24
Morphology

Complex equant crystals, massive.

Type-locality form

Masses, with dimensions 5x4x3 cm and 7x4x3 cm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
46.34%
14SiSiliconSilicon228.08556.170
27.11%
11NaSodiumSodium222.99045.980
22.20%
4BeBerylliumBeryllium19.0129.012
4.35%
Total207.156100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ca
  • K
  • S

In other languages

German
Chkalovit
Italian
Chkalovite
Chinese
硅铍钠石
Russian
Чкаловит

Classification

Strunz
10th ed.

9.DM.20

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DMInosilicates with 6-periodic single chainsGroup
  • 9.DM.20ChkaloviteSpecies
Dana
8th ed.

65.05.02.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.05Single-Width Unbranched Chains, W=1 with chains P=6Type
  • 65.05.02— unnamed intermediate level —Group
  • 65.05.02.01ChkaloviteSpecies
CIM

14.3.5

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.5ChkaloviteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1939Gerasimovskii, V.I. (1939) Chkalovite. Doklady Akademii Nauk SSSR: 22: 259-263.
  2. 1940(1940) New mineral names. American Mineralogist, 25 (5) 380
  3. 1956Pyatenko, Y.A., Bokii, G.B., Belov, N.V. (1956) The X-ray analysis of the crystal structure of chkalovite. Doklady Akademii Nauk SSSR: 108: 1077-1080. (in Russian).
  4. 1962Goryachev, A., Rogachev, D., Ignatev, O. (1962) Synthesis of Chkalovite. Doklady Akademii Nauk SSSR, 146(5), 1179.
  5. 1972Bauer, Y., Rykl, D. (1972) Synthetic Chkalovite. Kristallografiya, 17(3), 695.
