Chlormayenite

Ca12Al14O32[◻4Cl2]
IMA status
  • Approved
IMA symbol
Cmy
Discovered
1963
IMA approved
1963
Also known as
  • Brearleyite
  • Chlormayeniet
  • IMA1963-016
  • +3 more

Where it forms, where it's found

Geological setting

Thermally metamorphosed marly limestone inclusions in effusive volcanic rocks.

Type locality
Ettringer Feld
  1. Ettringen
  2. Vordereifel
  3. Mayen-Koblenz
  4. Rhineland-Palatinate
  5. Germany

50.3458°, 7.2222°

19recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Colorless
Streak
White
Density
2.85 g/cm³

Optical

Optical type
Isotropic
Surface relief
Moderate
Principal indices
n 1.600
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.600

Crystallography

Crystal system
Isometric
Space group
#209
Cell parameters
a = 11.98 Å
Z
2
Type-locality form

Colorless rounded grains having no recognizable crystal faces, with a maximum diameter of 60 microns.

Comment

Cell parameter ranges from 11.97-12.02 A. Former "chlormayenite" (IMA2010-062) has a = 11.9794 A.

Crystal structure

Synonyms

  • Brearleyite
  • Chlormayeniet
  • IMA1963-016
  • IMA2010-062
  • Mayenit
  • Mayenite

In other languages

German
Chlormayenit · IMA 1963-016
Spanish
Mayenita
Italian
clormayenite · mayenite
Russian
Хлормайенит

Classification

Strunz
10th ed.

4.CC.20

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CCWith large and medium-sized cationsGroup
  • 4.CC.20ChlormayeniteSpecies
Dana
8th ed.

07.11.03.01

  • 07Multiple OxidesClass
  • 07.11MiscellaneousType
  • 07.11.03— unnamed intermediate level —Group
  • 07.11.03.01ChlormayeniteSpecies
CIM

7.4.13

  • 7Oxides and HydroxidesClass
  • 7.4Oxides of Be, Mg and the alkaline earthsGroup
  • 7.4.13ChlormayeniteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1936Büssem, W. (1936) Die Struktur des Pentacalciumtrialuminats. Zeitschrift für Kristallographie, 95 (1-6). 175-188 doi:10.1524/zkri.1936.95.1.175 DOI: 10.1524/zkri.1936.95.1.175
  2. 1964Hentschel, G. (1964): Mayenit, 12CaO.7Al2O3, und Brownmillerit, 2CaO.(Al,Fe)2O3, zwei neue Minerale in den Kalksteineinschlüssen der Lava des Ettringer Bellerberges: Neues Jahrbuch für Mineralogie, Monatshefte, 1964: 22-29.
  3. 1965Nurse, R. W., Welch, J. H., Majumdar, A. J. (1965 a): The 12CaO.7Al2O3 phase in the CaO-Al2O3 system. Transactions and Journal of the British Ceramic Society, 64, 323-332.
  4. 1965Nurse, R. W.; Welch, J. H.; Majumdar, A. J. (1965 b): The CaO-Al2O3 system in a moisture-free atmosphere. Transactions and Journal of the British Ceramic Society, 64, 409-418.
  5. 1965American Mineralogist (1965): 50: 2106.
