Larnite

Ca2(SiO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lrn
Discovered
1929
Also known as

Where it forms, where it's found

Geological setting

contact metamorphic terranes involving sedimentary carbonate rocks.

Metamorphosed sedimentary carbonate formations in contact with basaltic rocks.

Type locality
Scawt Hill
  1. Larne
  2. County Antrim
  3. Northern Ireland
  4. UK

54.9105°, -5.9154°

60recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · gray · colorless in thin section
Cleavage
Distinct/Good

(100) good; (010) imperfect

Density
3.28 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 60 – 63° · 2V calc = 74°
Refractive index
1.7 – 1.74
Surface relief
High
Principal indices
nα 1.700 – 1.715 · nβ 1.715 – 1.723 · nγ 1.725 – 1.740
Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]250 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation250 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.502(1) Å · b = 6.745(1) Å · c = 9.297(1) Å
Cell angles
β = 94.59(2) °
Ratio a:b:c
1 : 1.226 : 1.690
Z
4
Twinning

Common. Polysynthetic parallel to (100).

Comment

Space Group: P21/n:

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium240.07880.156
46.54%
8OOxygenOxygen415.99963.996
37.15%
14SiSiliconSilicon128.08528.085
16.31%
Total172.237100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • Na
  • H2O
  • C
  • P

Synonyms

  • B-Ca2SiO4
  • Belit
  • Belita
  • Belite
  • Belith
  • Felit
  • Felita
  • Felite
  • β-C2S
  • β-Ca2SiO4

In other languages

French
Larnite
German
Larnit
Italian
Larnite

Classification

Strunz
10th ed.

9.AD.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ADNesosilicates without additional anions; cations in [6] and/or greater coordinationGroup
  • 9.AD.05LarniteSpecies
Dana
8th ed.

51.05.01.01

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.05Insular SiO4 Groups Only with cations in >[6] coordinationType
  • 51.05.01— unnamed intermediate level —Group
  • 51.05.01.01LarniteSpecies
CIM

14.5.6

  • 14Silicates not Containing AluminumClass
  • 14.5Silicates of CaGroup
  • 14.5.6LarniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1929Schairer, J.F. (1929) New mineral names. American Mineralogist: 14: 338-340.
  2. 1929Tilley, C. E. (1929) On larnite (calcium orthosilicate, a new mineral) and its associated minerals from the limestone contact-zone of Scawt Hill, Co. Antrim. Mineralogical Magazine and Journal of the Mineralogical Society, 22 (125) 77-86 doi:10.1180/minmag.1929.022.125.01 DOI: 10.1180/minmag.1929.022.125.01
  3. 1966Bridge, Thomas E. (1966) Bredigite, larnite, and γ dicalcium silicates from Marble Canyon. American Mineralogist, 51 (11-12) 1766-1774
  4. 1973Moore, Paul Brian (1973) Bracelets and pinwheels: A topological-geometrical approach to the calcium orthosilicate and alkali sulfate structures. American Mineralogist, 58 (1-2) 32-42
  5. 1977Jost, K. H., Ziemer, B., Seydel, R. (1977) Redetermination of the structure of β-dicalcium silicate. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 33 (6) 1696-1700 doi:10.1107/s0567740877006918DOI: 10.1107/s0567740877006918
