Claringbullite

Cu4ClF(OH)6
IMA status
  • Approved
IMA symbol
Cgb
Discovered
1976
Also known as
  • Claringbulliet
  • Fejerite
  • IMA1976-029

Where it forms, where it's found

Type locality
M'sesa Mine
  1. Kambove
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-10.8497°, 26.6064°

16recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent · Translucent
Colour
Blue

Pale blue in transmitted light.

Cleavage
Perfect

Perfect on (0001); distinct on (1010) and (1120).

Density
3.9 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.78 – 1.782
Surface relief
High
Principal indices
nω 1.782 · nε 1.78
Pleochroism
Not Visible
Michel-Lévy diagramhighlighted lineδ = 0.0020
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]20 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation20 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 6.6733(5) Å · c = 9.185(1) Å
Z
2
Morphology

Thin plates in slightly divergent groups. Crystals are flattened on (0001).

Type-locality form

Slightly divergent group of blue plates up to 1 mm across on cuprite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper463.546254.184
61.89%
8OOxygenOxygen615.99995.994
23.38%
17ClChlorineChlorine135.45035.450
8.63%
9FFluorineFluorine118.99818.998
4.63%
1HHydrogenHydrogen61.0086.048
1.47%
Total410.674100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Claringbulliet
  • Fejerite
  • IMA1976-029

In other languages

German
Claringbullit · IMA 1976-029
Italian
Claringbullite
Chinese
水羟氯铜矿

Classification

Strunz
10th ed.

3.DA.15

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DAWith Cu, etc., without PbGroup
  • 3.DA.15ClaringbulliteSpecies
Dana
8th ed.

10.05.06.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.05Am(O,OH)pXqType
  • 10.05.06— unnamed intermediate level —Group
  • 10.05.06.01ClaringbulliteSpecies
CIM

8.2.10

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.2Halides of CuGroup
  • 8.2.10ClaringbulliteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1977Fejer, E. E., Clark, A. M., Couper, A. G., Elliott, C. J. (1977) Claringbullite, a new hydrated copper chloride. Mineralogical Magazine, 41 (320) 433-436 doi:10.1180/minmag.1977.041.320.02 DOI: 10.1180/minmag.1977.041.320.02
  2. 1978Fleischer, Michael; Pabst, Adolf, White, John Sampson (1978) New mineral names. American Mineralogist, 63 (7-8). 793-796
  3. 1995Burns, P.C., Cooper, M.A., Hawthorne, F.C. (1995) Claringbullite: a Cu2+ oxysalt with Cu2+ in trigonal-prismatic coordination. The Canadian Mineralogist: 33: 633-639.
  4. 2003Frost, Ray L., Williams, Peter A., Kloprogge, J. Theo, Martens, Wayde (2003) Raman spectroscopy of the copper chloride minerals nantokite, eriochalcite and claringbullite – implications for copper corrosion. Neues Jahrbuch für Mineralogie - Monatshefte, 2003 (10) 433-445 doi:10.1127/0028-3649/2003/2003-0433 DOI: 10.1127/0028-3649/2003/2003-0433
  5. 2005(2005) Claringbullite. Handbook of Mineralogy. Mineralogical Society of America
