Clino-ferro-suenoite

◻Mn2+2(Fe2+5)(Si8O22)(OH)2
IMA status
  • Approved
IMA symbol
Cfsue
Also known as
  • Clino-ferro-suenoiet
  • Hillangsite
  • Manganogrunerite
  • +1 more

Where it forms, where it's found

Geological setting

in iron–manganese skarn. t formed by partial replacement of manganoan fayalite during retrograde metamorphism.

Type locality
Hillängs Mine
  1. Ludvika
  2. Dalarna County
  3. Sweden

60.1469°, 15.2194°

58recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale greenish-yellow to colorless
Cleavage
Perfect

Cleavage parallel to (110) and (010) is perfect and good, respectively

Density
3.46 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80° · 2V calc = 80.9°
Refractive index
1.67 – 1.705
Surface relief
High
Principal indices
nα 1.670 · nβ 1.690 · nγ 1.705
Pleochroism
Non-pleochroic
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.598(1) Å · b = 18.3179(2) Å · c = 5.3345(1) Å
Cell angles
β = 102.163(1) °
Ratio a:b:c
1 : 1.909 : 0.556
Z
2
Type-locality form

Individual crystals, up to 0.5 mm in length, are subhedral

Crystal structure

Synonyms

  • Clino-ferro-suenoiet
  • Hillangsite
  • Manganogrunerite
  • Silfbergite

In other languages

German
Klino-Ferro-Suenoit · Manganogrunerit
Italian
clino-ferro-suenoite
Chinese
锰铁闪石

Classification

Strunz
10th ed.

9.DE.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.10Clino-ferro-suenoiteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. Holtstam, D., Cámara, F., Skogby, H., De Leo, A., and Karlsson, A.: Clino-ferro-suenoite, IMA 2024-032, in: CNMNC Newsletter 81, Eur. J. Mineral., 36, https://doi.org/10.5194/ejm-36-917-2024, 2024.
  2. 1855Kenngott (1855)
  3. 1892Dana (1892)
  4. 2018Oberti, Roberta, Boiocchi, Massimo, Hawthorne, Frank C., Ciriotti, Marco E., Revheim, Olav, Bracco, Roberto (2018) Clino-suenoite, a newly approved magnesium-iron-manganese amphibole from Valmalenco, Sondrio, Italy. Mineralogical Magazine, 82 (1) 189-198 doi:10.1180/minmag.2017.081.034DOI: 10.1180/minmag.2017.081.034
  5. 2020(2020) Clino-ferro-suenoite. Handbook of Mineralogy. Mineralogical Society of America
