Ferrokinoshitalite

BaFe2+3(Si2Al2)O10(OH)2
IMA status
  • Approved
IMA symbol
Fkns
Also known as
  • Ferrokinoshitaliet
  • Ferrokinoshitalit
  • IMA1999-026

Where it forms, where it's found

Type locality
Broken Hill Mine
  1. Aggeneys
  2. Khâi-Ma Local Municipality
  3. Namakwa District Municipality
  4. Northern Cape
  5. South Africa

-29.2506°, 18.7834°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Dark green
Streak
Green
Tenacity
brittle
Cleavage
Perfect

Perfect (001)

Fracture
None observed
Density
3.69 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20°
Refractive index
1.68 – 1.7
Surface relief
High
Principal indices
nα 1.68 · nβ 1.68 · nγ 1.7
Pleochroism
Strong

X = grass green, Y = dark brown-green, Z = dark greenish gray-brown

Dispersion
Calculated
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 5.389(1) Å · b = 9.337(2) Å · c = 10.054(2) Å
Cell angles
β = 100.53 °
Ratio a:b:c
1 : 1.733 : 1.866
Z
2
Morphology

Tabular crystals

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
31.53%
26FeIronIron355.845167.535
27.51%
56BaBariumBarium1137.327137.327
22.55%
14SiSiliconSilicon228.08556.170
9.22%
13AlAluminiumAluminium226.98253.964
8.86%
1HHydrogenHydrogen21.0082.016
0.33%
Total609.000100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferrokinoshitaliet
  • Ferrokinoshitalit
  • IMA1999-026

In other languages

German
Ferrokinoshitalith · IMA 1999-026
Italian
Ferrokinoshitalite

Classification

Strunz
10th ed.

9.EC.35

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.35FerrokinoshitaliteSpecies

Group, growth & confusion

Often grow together
8 minerals

Literature, links & citation

Citations
  1. 1999Guggenheim, S. and Frimmel, H.E. (1999) Ferrokinoshitalite, a new species of brittle mica from the Broken Hill mine, South Africa: structural and mineralogical characterization. Canadian Mineralogist: 37: 1445-1452.
  2. 2023(2023) Ferrokinoshitalite. Handbook of Mineralogy. Mineralogical Society of America
