Cooperite

PtS
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cpe
Discovered
1928
Also known as
  • Cooperite (of Wartenweiler)

Where it forms, where it's found

Geological setting

Norites.

Type locality
Mokopane
  1. Mogalakwena Local Municipality
  2. Waterberg District Municipality
  3. Limpopo
  4. South Africa

-24.1833°, 29.0167°

137recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Steel gray to silvery white
Tenacity
brittle
Cleavage
Distinct/Good

On (011)

Fracture
Conchoidal
Density
9.5 g/cm³

Optical

Pleochroism
Visible

From white to creamy white to bluish white

Optical colour
Light brown
Anisotropism
Strong, greenish gray to whitish yellow to brown gray and brown
Tropism
Anisotropic
Reflectance R%
(40.9,46.6) 400, (42.0,47.3) 420, (42.6,47.9) 440, (42.7,48.3) 460, (42.2,48.4) 480, (41.5,48.2) 500, (40.4,47.8) 520, (39.4,47.2) 540, (38.5,46.6) 560, (37.8,46.1) 580, (37.2,45.5) 600, (36.6,45.1) 620, (36.0,44.7) 640, (35.6,44.2) 660, (35.1,43.7) 680, (34.6,43.3) 700
UV response
Not fluorescent in UV
Reflected-light panel
38.9 %anisotropic · dual curve
Specimen sRGB 215, 156, 91
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong, greenish gray to whitish yellow to brown gray and brown
Reflected colour
Light brown

Crystallography

Crystal system
Tetragonal
Space group
P42/mmc
Cell parameters
a = 3.4700 Å · c = 6.1096 Å
Z
2
Morphology

Distorted crystal fragments, irregular grains to 1.5mm

Twinning

Occasionally

Type-locality form

Silvery white metallic to steel gray metallic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
78PtPlatinumPlatinum1195.084195.084
85.89%
16SSulfurSulfur132.06032.060
14.11%
Total227.144100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cooperite (of Wartenweiler)

In other languages

French
Cooperite
German
Cooperit
Spanish
Cooperita
Italian
Cooperite
Chinese
硫铂矿

Classification

Strunz
10th ed.

2.CC.35b

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CCWith Ni, Fe, Co, PGE, etc.Group
  • 2.CC.35bCooperiteSpecies
Dana
8th ed.

02.08.05.01

  • 02SulfidesClass
  • 02.08AmXp, with m:p = 1:1Type
  • 02.08.05Cooperite GroupGroup
  • 02.08.05.01CooperiteSpecies
CIM

3.12.44

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.12Sulphides etc. of the platinum metalsGroup
  • 3.12.44CooperiteSpecies

Group, growth & confusion

Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1928Wartenweiler, F. (1928) Discussion on a new platinum mineral in the Rustenburg norites. Journal of the Chemical, Metallurgical, and Mining Society of South Africa: 28: 281-283.
  2. 1929Schairer, J.F. (1929) New mineral names. American Mineralogist: 14: 338-340 (339).
  3. 1931Foshag, W.F. (1931) New mineral names. American Mineralogist: 16: 409-410.
  4. 1932Bannister, F. A. (1932) Determination of minerals in platinum concentrates from the Transvaal by X-ray methods. Mineralogical Magazine and Journal of the Mineralogical Society, 23 (138) 188-206 doi:10.1180/minmag.1932.023.138.05 DOI: 10.1180/minmag.1932.023.138.05
  5. 1933Foshag, W..F (1933) New mineral names. American Mineralogist: 18: 79-79.
