Creaseyite

Cu2Pb2Fe3+2Si5O17 · 6H2O
IMA status
  • Approved
IMA symbol
Cse
Discovered
1974
IMA approved
1974
Also known as
  • Creaseyiet
  • IMA1974-044

Where it forms, where it's found

Geological setting

Breccia of andesite loosely cemented with iron oxides and wulfenite.

Type locality
Mammoth-Saint Anthony Mine
  1. St. Anthony deposit
  2. Tiger
  3. Mammoth Mining District
  4. Pinal County
  5. Arizona
  6. USA

32.7064°, -110.6831°

32recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale green to yellow-green · yellow in thin section
Streak
Light green.
Cleavage
Poor/Indistinct

Poor on (010)

Density
4.1 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 69° · 2V calc = 70°
Refractive index
1.737 – 2
Surface relief
Very high
Principal indices
nα 1.737 – 2 · nβ 1.747 – 2 · nγ 1.768 – 2
Pleochroism
Weak

X = yellow-green; Y = green; Z = yellow-green

Dispersion
r > v moderate
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0155
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]155 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation155 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#50
Cell parameters
a = 12.502(8) Å · b = 21.402(11) Å · c = 7.303(6) Å
Ratio a:b:c
1 : 1.712 : 0.584
Z
4
Type-locality form

Densely packed spherules of small size (less than 1 mm diameter). Matted fibres lying between spherules.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
35.31%
8OOxygenOxygen2315.999367.977
31.35%
14SiSiliconSilicon528.085140.425
11.96%
29CuCopperCopper263.546127.092
10.83%
26FeIronIron255.845111.690
9.52%
1HHydrogenHydrogen121.00812.096
1.03%
Total1173.680100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Zn

Synonyms

  • Creaseyiet
  • IMA1974-044

In other languages

German
Creaseyit · IMA 1974-044
Italian
Creaseyite
Chinese
硅铁铜铅石

Classification

Strunz
10th ed.

9.HH.15

  • 9SilicatesClass
  • 9.HUnclassified silicatesDivision
  • 9.HHWith PbGroup
  • 9.HH.15CreaseyiteSpecies
Dana
8th ed.

78.07.02.01

  • 78Unclassified SilicatesClass
  • 78.07Unclassified silicates wholly unclassified silicatesType
  • 78.07.02— unnamed intermediate level —Group
  • 78.07.02.01CreaseyiteSpecies
CIM

14.13.10

  • 14Silicates not Containing AluminumClass
  • 14.13Silicates of PbGroup
  • 14.13.10CreaseyiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1975Williams, Sidney A., Bideaux, Richard A. (1975) Creaseyite, Cu2Pb2(Fe,Al)2Si5O17·6H2O a new mineral from Arizona and Sonora. Mineralogical Magazine, 40 (311) 227-231 doi:10.1180/minmag.1975.040.311.02 DOI: 10.1180/minmag.1975.040.311.02
  2. 1976Fleischer, Michael, Cabri, Louis J. (1976) New Mineral names. American Mineralogist, 61 (5-6) 502-504
  3. 2001(2001) Creaseyite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2012Frost, Ray L., Xi, Yunfei (2012) Vibrational spectroscopic study of the mineral creaseyite Cu2Pb2(Fe,Al)2(Si5O17)·6H2O – A zeolite mineral?. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 94. 6-11 doi:10.1016/j.saa.2012.03.046DOI: 10.1016/j.saa.2012.03.046
  5. 2013Malcherek, Thomas, Köslin, Bastian, Schlüter, Jochen (2013) The crystal structure of creaseyite: a disordered, nanoporous lead iron copper alumosilicate. Zeitschrift für Kristallographie - Crystalline Materials, 228 (3) 134-139 doi:10.1524/zkri.2013.1572DOI: 10.1524/zkri.2013.1572
