Cuprorivaite

CaCuSi4O10
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cuv
Discovered
1938
Also known as
  • Ägyptisch Blau
  • Ägyptischblau
  • Cuprorivaiet
  • +4 more

Where it forms, where it's found

Type locality
Mount Vesuvius
  1. Metropolitan City of Naples
  2. Campania
  3. Italy
9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Blue
Tenacity
brittle
Cleavage
Perfect

on (001)

Density
3.08 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.59 – 1.633
Surface relief
Moderate
Principal indices
nω 1.633 · nε 1.590
Pleochroism
Visible

Blue - O Pale rose - nearly colorless - E

Notes

artificial RIs 1.636 and 1.591+0.003

Michel-Lévy diagramhighlighted lineδ = 0.0430
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]430 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation430 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P4/ncc
Cell parameters
a = 7.30(1) Å · c = 15.12(2) Å
Z
4
Morphology

Tabular (001)

Type-locality form

Aggregates of small grains.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
42.56%
14SiSiliconSilicon428.085112.340
29.88%
29CuCopperCopper163.54663.546
16.90%
20CaCalciumCalcium140.07840.078
10.66%
Total375.954100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Na
  • K
  • S

Synonyms

  • Ägyptisch Blau
  • Ägyptischblau
  • Cuprorivaiet
  • Egyptian Blue
  • Frittenblau
  • Kupferfritte
  • Pompeijanisch Blau

In other languages

German
Cuprorivait
Italian
Cuprorivaite

Classification

Strunz
10th ed.

9.EA.05

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EASingle nets of tetrahedra with 4-, 5-, (6-), and 8-membered ringsGroup
  • 9.EA.05CuprorivaiteSpecies
Dana
8th ed.

71.02.03.01

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.02Sheets of 6-membered rings with 2:1 layersType
  • 71.02.03Cuprorivaite groupGroup
  • 71.02.03.01CuprorivaiteSpecies
CIM

14.2.8

  • 14Silicates not Containing AluminumClass
  • 14.2Silicates of CuGroup
  • 14.2.8CuprorivaiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1938Minguzzi, C. (1938) Cuprorivaite: un nuovo minerale. Periodico di Mineralogia – Roma, 333-345.
  2. 1939Foshag, W.F. (1939) New mineral names. American Mineralogist, 24, 350-350.
  3. 1959Pabst, A. (1959) Structures of some tetragonal sheet silicates. Acta Crystallographica, 12 (10) 733-739 doi:10.1107/s0365110x5900216xDOI: 10.1107/s0365110x5900216x
  4. 1962Mazzi, Fimenzo, Pabst, A. (1962) Reexamination of cuprorivaite. American Mineralogist, 47 (3-4). 409-411
  5. 1993Chakoumakos, Bryan C., Fernandez-Baca, Jaime A., Boatner, Lynn A. (1993) Refinement of the Structures of the Layer Silicates MCuSi4O10 (M = Ca, Sr, Ba) by Rietveld Analysis of Neutron Powder Diffraction Data. Journal of Solid State Chemistry, 103. 105-113 doi:10.1006/jssc.1993.1083DOI: 10.1006/jssc.1993.1083
