Dachiardite-Ca

Ca2(Si20Al4)O48 · 13H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Dac-Ca
Also known as
  • Dachiardiet-Ca

Where it forms, where it's found

Type locality
La Speranza (Pisani's Quarry)
  1. San Piero in Campo
  2. Campo nell'Elba
  3. Livorno Province
  4. Tuscany
  5. Italy
14recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky
Transparency
Transparent
Colour
Colorless
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (001), (100)

Fracture
Irregular/Uneven · Conchoidal
Density
2.165 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 58 – 73° · 2V calc = 72 – 80°
Refractive index
1.488 – 1.499
Surface relief
Low
Principal indices
nα 1.488 – 1.494 · nβ 1.49 – 1.496 · nγ 1.494 – 1.499
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0055
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]55 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation55 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 18.625 Å · b = 7.508 Å · c = 10.247 Å
Cell angles
β = 108.056 °
Ratio a:b:c
1 : 0.403 : 0.550
Z
1
Morphology

Typically as bladed prismatic crystals, commonly fibrous. Radiating aggregates.

Twinning

Material from Elba exhibits twinning on (110) as rare cyclical eightlings.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6115.999975.939
55.71%
14SiSiliconSilicon2028.085561.700
32.06%
13AlAluminiumAluminium426.982107.928
6.16%
20CaCalciumCalcium240.07880.156
4.57%
1HHydrogenHydrogen261.00826.208
1.50%
Total1751.931100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dachiardiet-Ca

In other languages

German
Dachiardit-Ca
Italian
Dachiardite-Ca
Chinese
钙环晶沸石

Classification

Strunz
10th ed.

9.GD.40

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.40Dachiardite-CaSpecies
Dana
8th ed.

77.01.24.02

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.24— unnamed intermediate level —Group
  • 77.01.24.02Dachiardite-CaSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1906D'Achiardi, G. (1906) Zeoliti del filone della speranza presso S. Piero in Campo (Elba). Atti della Societa Toscana di Scienze Naturali. Processi Verbali: 22: 150-165.
  2. 1925Berman, H. (1925) Notes on dachiardite. American Mineralogist: 10: 421-428.
  3. 1925De-Angelis (1925) Alcune nuove osservazioni sulla dachiardite. R. C. Accademia dei Lincei: 6(2): 133-135.
  4. 1942Bonatti, S. (1942) ricerche sulla dachiardite. Mem. Soc. Tosc. Sci. Nat.: 50: 14-25.
  5. 1960Bonatti S., Gottardi G. (1960) Dati ottici e strutturali sulla dachiardite. Periodico di Mineralogia, 103-108.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Dachiardite-Ca — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/dachiardite-ca-6895},
  note      = {Accessed 2026-05-11}
}
