Dachiardite-Na

Na4(Si20Al4)O48 · 13H2O
IMA status
  • Approved
IMA symbol
Dac-Na
Also known as
  • Dachiardiet-Na
  • Na Dachiardit
  • Na Dachiardite
  • +4 more

Where it forms, where it's found

Geological setting

Basalt.

Type locality
La Palaccia-Orli di Fassa (Palacia-Auf der Schneid)
  1. Duron Valley
  2. Campitello di Fassa
  3. Trento Province
  4. Trentino-Alto Adige/Südtirol
  5. Italy

46.5007°, 11.6841°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky
Transparency
Transparent
Colour
Colorless · red-orange
Streak
White
Density
2.16 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 58 – 73° · 2V calc = 72 – 80°
Refractive index
1.488 – 1.499
Surface relief
Low
Principal indices
nα 1.488 – 1.494 · nβ 1.49 – 1.496 · nγ 1.494 – 1.499
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0055
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]55 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation55 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 18.647(7) Å · b = 7.506(4) Å · c = 10.296(4) Å
Cell angles
β = 108.37(3) °
Ratio a:b:c
1 : 0.403 : 0.552
Z
1
Type-locality form

Thin, parallel fibers.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6115.999975.939
55.33%
14SiSiliconSilicon2028.085561.700
31.85%
13AlAluminiumAluminium426.982107.928
6.12%
11NaSodiumSodium422.99091.960
5.21%
1HHydrogenHydrogen261.00826.208
1.49%
Total1763.735100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dachiardiet-Na
  • Na Dachiardit
  • Na Dachiardite
  • Natriumdachiardit
  • Sodium Dachiardite
  • Svetlozarit
  • Svetlozarite

In other languages

German
Dachiardit-Na
Italian
dachiardite-Na
Chinese
钠环晶沸石

Classification

Strunz
10th ed.

9.GD.40

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.40Dachiardite-NaSpecies
Dana
8th ed.

77.01.06.05

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.06Mordenite and related speciesGroup
  • 77.01.06.05Dachiardite-NaSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1906D'Achiardi, G. (1906) Zeoliti del filone della Speranza presso S. Piero in Campo (Elba). Atti della Società Toscana di Scienze Naturali: 22: 150-165.
  2. 1975Alberti, Alberto (1975) Sodium-rich dachiardite from Alpe di Siusi, Italy. Contributions to Mineralogy and Petrology, 49 (1) 63-66 doi:10.1007/bf00371079DOI: 10.1007/bf00371079
  3. 1975Vezzalini, G., Alberti, A. (1975) Le zeoliti dell'Alpe di Siusi. Rendiconti della Società Italiana di Mineralogia e Petrologia: 31: 711-719.
  4. 1977Yoshimura, T., Wakabayashi, S. (1977) Na-dachiardite and associated high-silica zeolites from Tsugawa, Northeast Japan. Science Reports of Niigata University, Series E: Geology and Mineralogy: 4: 49-65.
  5. 1979Demartin, F., Stolcis, T. (1979) Nuovo giacimento di dachiardite in Val di Fassa. Rivista Mineralogica Italiana: 1979: 93-95.
