Erionite-Ca

Ca5[Si26Al10O72] · 30H2O
IMA status
  • Approved
IMA symbol
Eri-Ca
Also known as
  • Erioniet-Ca

Where it forms, where it's found

Geological setting

In thoroughly weathered and altered olivine basalt and andesite.

Type locality
Maze (Mazé)
  1. Niigata City
  2. Niigata Prefecture
  3. Japan
26recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky
Transparency
Transparent
Colour
Colorless · white
Streak
White
Density
2.08 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.4711 – 1.474
Surface relief
Low
Principal indices
nω 1.4711 · nε 1.474
Extinction
Parallel extinction, positive elongation.
Michel-Lévy diagramhighlighted lineδ = 0.0029
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]29 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation29 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 13.333(1) Å · c = 15.091(2) Å
Type-locality form

Woolly white radial aggregates of fibers. The fibers reach 2 x 0.05 mm in size.

Comment

Cell parameters from Harada et al 1967 (type material).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen10215.9991631.898
56.41%
14SiSiliconSilicon2628.085730.210
25.24%
13AlAluminiumAluminium1026.982269.820
9.33%
20CaCalciumCalcium540.078200.390
6.93%
1HHydrogenHydrogen601.00860.480
2.09%
Total2892.798100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Erioniet-Ca

In other languages

German
Erionit-Ca
Italian
erionite-Ca
Japanese
灰エリオン沸石

Classification

Strunz
10th ed.

9.GD.20

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.20Erionite-CaSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1967Harada, Kazuo, Iwamoto, Shigeki, Kihara, and Kuniaki (1967) Erionite, phillipsite, gonnardite in the amygdales of altered basalt from Mazé, Niigata prefecture, Japan. American Mineralogist, 52 (11-12) 1785-1794
  2. 1969Sheppard, Richard A., Gude, Arthur J., 3rd, (1969) Chemical composition and physical properties of the related zeolites offretite and erionite. American Mineralogist, 54 (5-6) 875-886
  3. 1998Gualtieri, A., Artioli, G., Passaglia, E., Bigi, S., Viani, A., Hanson, J. C. (1998) Crystal structure-crystal chemistry relationships in the zeolites erionite and offretite. American Mineralogist, 83 (5) 590-606 doi:10.2138/am-1998-5-619 DOI: 10.2138/am-1998-5-619
  4. 1998Passaglia, E., Artioli, G., Gualtieri, A. (1998) Crystal chemistry of the zeolites erionite and offretite. American Mineralogist, 83 (5-6) 577-589
