Erionite-K

K10[Si26Al10O72] · 30H2O
IMA status
  • Approved
IMA symbol
Eri-K
Also known as
  • Erioniet-K

Where it forms, where it's found

Type locality
Rome
  1. Malheur County
  2. Oregon
  3. USA

42.8383°, -117.6285°

21recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky

Optical

Optical type
Uniaxial (+)
Refractive index
1.4711 – 1.474
Surface relief
Low
Principal indices
nω 1.4711 · nε 1.474
Michel-Lévy diagramhighlighted lineδ = 0.0029
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]29 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation29 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 13.227(1) Å · c = 15.075(3) Å
Comment

Cell parameters from Passaglia et al. 1998.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen10215.9991631.898
52.93%
14SiSiliconSilicon2628.085730.210
23.68%
19KPotassiumPotassium1039.098390.980
12.68%
13AlAluminiumAluminium1026.982269.820
8.75%
1HHydrogenHydrogen601.00860.480
1.96%
Total3083.388100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Erioniet-K

In other languages

German
Erionit-K
Italian
erionite-K

Classification

Strunz
10th ed.

9.GD.20

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.20Erionite-KSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1964Eberly, P.E. (1964) Absorption properties of naturally occurring erionite and its cationic-exchanged forms. American Mineralogist, 49, 30-40.
  2. 1969Sheppard, Richard A., Gude, Arthur J., 3rd, (1969) Chemical composition and physical properties of the related zeolites offretite and erionite. American Mineralogist, 54 (5-6) 875-886
  3. 1998Gualtieri, A., Artioli, G., Passaglia, E., Bigi, S., Viani, A., Hanson, J. C. (1998) Crystal structure-crystal chemistry relationships in the zeolites erionite and offretite. American Mineralogist, 83 (5) 590-606 doi:10.2138/am-1998-5-619 DOI: 10.2138/am-1998-5-619
  4. 1998Passaglia, E., Artioli, G., Gualtieri, A. (1998) Crystal chemistry of the zeolites erionite and offretite. American Mineralogist, 83 (5-6) 577-589
  5. 2001(2001) Erionite-K. Handbook of Mineralogy. Mineralogical Society of America
