Ermakovite

(NH4)(As2O3)2Br
IMA status
  • Approved
IMA symbol
Ekv
IMA approved
2020
Also known as
  • Ermakoviet
  • IMA2020-054

Where it forms, where it's found

Geological setting

Coal-fire-driven exhalative processes within a fumarole.

Type locality
Kukhi-Malik tract
  1. Fan-Jagnob coal deposit
  2. Ayni District
  3. Sughd
  4. Tajikistan

39.1952°, 68.5708°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789101 – 1.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow

Zoned with a transparent yellowish core and semi-transparent yellow rim.

Streak
White with a yellowish tint
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
3.64 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.716 – 1.96
Surface relief
Very high
Principal indices
nω 1.960 · nε 1.716
Pleochroism
Non-pleochroic
Michel-Lévy diagramhighlighted lineδ = 0.2440
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2440 nm5th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2440 nm
Order5th order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P6/mmm
Cell parameters
a = 5.271(3) Å · c = 9.157(6) Å
Z
1
Morphology

Tabular or prismatic, hexagonal crystals, up to 200 μm, with the c (001), m (010), and p (014) forms; commonly as spherolitic and multi-twinned intergrowths.

Twinning

Multi-twinned intergrowths.

Type-locality form

Tabular or prismatic, hexagonal crystals, up to 200 μm, with the c (001), m (010), and p (014) forms; commonly as spherolitic and multi-twinned intergrowths.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
33AsArsenicArsenic474.922299.688
60.71%
8OOxygenOxygen615.99995.994
19.44%
35BrBromineBromine179.90479.904
16.19%
7NNitrogenNitrogen114.00714.007
2.84%
1HHydrogenHydrogen41.0084.032
0.82%
Total493.625100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ermakoviet
  • IMA2020-054

In other languages

German
Ermakovit · IMA 2020-054

Classification

Strunz
10th ed.

3.C0

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.C0— unnamed intermediate level —Group
  • 3.C0ErmakoviteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2020Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2020) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 58. European Journal of Mineralogy, 32 (6) 645-651 doi:10.5194/ejm-32-645-2020 DOI: 10.5194/ejm-32-645-2020
  2. 2022(2022) Ermakovite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2023Karpenko, Vladimir Yu., Pautov, Leonid A., Siidra, Oleg I., Mirakov, Mirak A., Zaitsev, Anatoly N., Plechov, Pavel Yu., Makhmadsharif, Saimudasir (2023) Ermakovite (NH4)(As2O3)2Br, a new exhalative arsenite bromide mineral from the Fan-Yagnob coal deposit, Tajikistan. Mineralogical Magazine, 87 (1) 69-78 doi:10.1180/mgm.2022.116DOI: 10.1180/mgm.2022.116
