Ernienickelite

NiMn4+3O7 · 3H2O
IMA status
  • Approved
IMA symbol
Enk
Also known as
  • Ernienickeliet
  • IMA1993-002

Where it forms, where it's found

Type locality
SM7 pit
  1. Siberia Goldfield (Waverley)
  2. Kalgoorlie-Boulder Shire
  3. Western Australia
  4. Australia

-30.2400°, 120.9957°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black · red-brown cast.
Streak
yellow-brown
Tenacity
brittle
Fracture
Splintery
Density
3.84 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.97 – 2
Surface relief
Very high
Principal indices
nω 2.00 · nε 1.97
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#78
Cell parameters
a = 7.5142(2) Å · c = 20.52(2) Å
Z
6
Morphology

platy crystals, hexagonal to nearly circular

Twinning

on {-12-10}

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese354.938164.814
42.31%
8OOxygenOxygen1015.999159.990
41.07%
28NiNickelNickel158.69358.693
15.07%
1HHydrogenHydrogen61.0086.048
1.55%
Total389.545100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Co
  • Mg

Synonyms

  • Ernienickeliet
  • IMA1993-002

In other languages

German
Ernienickelit · IMA 1993-002
Italian
Ernienickelite
Chinese
锰镍矿

Classification

Strunz
10th ed.

4.FL.20

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FLHydroxides with H2O +- (OH); sheets of edge-sharing octahedraGroup
  • 4.FL.20ErnienickeliteSpecies
Dana
8th ed.

07.08.02.04

  • 07Multiple OxidesClass
  • 07.08AB3X7Type
  • 07.08.02Chalcophanite GroupGroup
  • 07.08.02.04ErnienickeliteSpecies

Group, growth & confusion

In the same group
3 members
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1992Gorshkov, A.I., Kapustkin, G.R., Sivtsov, A.V., Lazarenko, I.M., Subrovinskiy, L.S. (1992) Ni-chalcophanite: a new variety of the mineral from a weathering crust on ultramafic rocks of the Kempirsay massif (southern Urals). Izvestiya Akademii Nauk Seriya Geologicheskaya: 11: 108-117. (in Russian)
  2. 1994Jambor, John L., Grew, Edward S. (1994) New Mineral Names. American Mineralogist, 79 (3-4) 387-391
  3. 1994Grice, Joel D., Gartrell, B., Gault, Robert A., Van Velthuizen, Jerry (1994) Ernienickelite, NiMn3O7 · 3H2O, a new mineral species from the Siberia complex, Western Australia: comments on the chalcophanite group. The Canadian Mineralogist, 32 (2) 333-337
  4. 2005(2005) Ernienickelite. Handbook of Mineralogy. Mineralogical Society of America
