Euchlorine

KNaCu3O(SO4)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ecr
Also known as
  • Euchlorien
  • Euchlorite

Where it forms, where it's found

Type locality
Mount Vesuvius
  1. Metropolitan City of Naples
  2. Campania
  3. Italy
13recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Translucent
Colour
Emerald-green · emerald-green in transmitted light.
Cleavage
Imperfect/Fair

Cleavage observed in two unstated directions.

Density
3.27 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.58 – 1.644
Surface relief
Moderate
Principal indices
nα 1.580 · nβ 1.605 · nγ 1.644
Pleochroism
Visible

X = Pale grass green Y = Grass-green Z = Bright yellow-green

Dispersion
r < v
Notes

2V moderately large.

Michel-Lévy diagramhighlighted lineδ = 0.0640
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]640 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation640 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 18.41(5) Å · b = 9.43(3) Å · c = 14.21(5) Å
Cell angles
β = 113.7(3) °
Ratio a:b:c
1 : 0.512 : 0.772
Z
8
Morphology

Crystals are rectangular tablets (001) and slightly elongated [100]. As incrustations. Forms include: (010), (001) (120), (011), (013), (101), (103).

Comment

Space Group: C2/a.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
37.35%
29CuCopperCopper363.546190.638
34.23%
16SSulfurSulfur332.06096.180
17.27%
19KPotassiumPotassium139.09839.098
7.02%
11NaSodiumSodium122.99022.990
4.13%
Total556.893100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Euchlorien
  • Euchlorite

In other languages

German
Euchlorin
Italian
euclorina

Classification

Strunz
10th ed.

7.BC.30

  • 7SulfatesClass
  • 7.BSulfates (selenates, etc.) with additional anions, without H2ODivision
  • 7.BCWith medium-sized and large cationsGroup
  • 7.BC.30EuchlorineSpecies
Dana
8th ed.

30.03.01.01

  • 30Anhydrous Sulfates Containing Hydroxyl or HalogenClass
  • 30.03(AB)5(XO4)3ZqType
  • 30.03.01— unnamed intermediate level —Group
  • 30.03.01.01EuchlorineSpecies
CIM

25.2.16

  • 25SulphatesClass
  • 25.2Sulphates of Cu and AgGroup
  • 25.2.16EuchlorineSpecies

Group, growth & confusion

In the same group
1 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. Mineralogical Abstracts: 42: 22.
  2. 1869Scacchi, A. (1869) (as Euclorina).
  3. 1875Rammelsberg, Carl Friedrich (1875) Handbuch der Mineralchemie (2nd ed.) Wilhelm Engelmann, Leipzig.
  4. 1884Scacchi, E. (1884) Sull’euclorina, sull’eriocaleo e sul melanotallo. Rendiconto dell'Accademia delle Scienze Fisiche e Matematiche (sezione della Societa reale di Napoli) 23, 158-165 (as Euclorina).
  5. 1884Scacchi E (1884) Sull’euclorina, sull’eriocaleo e sul melanotallo. Rendiconto dell'Accademia delle Scienze Fisiche e Matematiche (sezione della Societa reale di Napoli) 23, 158-16
