Ferroericssonite

BaFe2+2Fe3+(Si2O7)O(OH)
IMA status
  • Approved
IMA symbol
Fers
IMA approved
2010
Also known as
  • Ferroericssoniet
  • IMA2010-025

Where it forms, where it's found

Geological setting

As late stage mineral in a sequence of minerals resulting from fluids interacting with a quartz–sanbornite vein along its margin with the country rock.

Type locality
Esquire No. 7 claim
  1. Big Creek
  2. Big Creek-Rush Creek Mining District
  3. Fresno County
  4. California
  5. USA

36.9167°, -119.2450°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Dark reddish brown
Streak
Brown
Tenacity
brittle
Cleavage

Two cleavages: (100) perfect and (011) good

Optical

Optical type
Biaxial (+) · 2V measured = 63° · 2V calc = 63.0°
Refractive index
1.827 – 1.92
Surface relief
Very high
Principal indices
nα 1.827 · nβ 1.845 · nγ 1.920
Dispersion
Parallel, r < v
Michel-Lévy diagramhighlighted lineδ = 0.0930
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]930 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation930 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 20.3459(10) Å · b = 7.0119(3) Å · c = 5.3879(4) Å
Cell angles
β = 94.874(7) °
Ratio a:b:c
1 : 0.345 : 0.265
Morphology

Flattened on (100) and elongate and striated parallel to [001].

Type-locality form

Crystals occur in dark reddish brown foliated masses of irregular, undulating striated blades up to several mm in length.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron355.845167.535
33.11%
8OOxygenOxygen915.999143.991
28.45%
56BaBariumBarium1137.327137.327
27.14%
14SiSiliconSilicon228.08556.170
11.10%
1HHydrogenHydrogen11.0081.008
0.20%
Total506.031100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferroericssoniet
  • IMA2010-025

In other languages

German
Ferroericssonit · IMA 2010-025
Italian
ferroericssonite

Classification

Strunz
10th ed.

9.00

  • 9SilicatesClass
  • 9.0— unnamed intermediate level —Division
  • 9.00— unnamed intermediate level —Group
  • 9.00FerroericssoniteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2010Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2010) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) CNMNC Newsletter No 4. Mineralogical Magazine, 74 (4) 797-800 doi:10.1180/s0026461x00038925 DOI: 10.1180/s0026461x00038925
  2. 2011Kampf, A. R., Roberts, A. C., Venance, K. E., Dunning, G. E., Walstrom, R. E. (2011) Ferroericssonite, the Fe2+ analogue of ericssonite, from eastern Fresno County, California, USA. The Canadian Mineralogist, 49 (2). 587-594 doi:10.3749/canmin.49.2.587DOI: 10.3749/canmin.49.2.587
  3. 2014Sokolova, Elena, Cámara, Fernando (2014) From structure topology to chemical composition. XVII. Fe3+ versus Ti4+: The topology of the HOH layer in ericssonite-2O, Ba2Fe3+2Mn4(Si2O7)2O2(OH)2, ferroericssonite, Ba2Fe3+2Fe2+4(Si2O7)2O2(OH)2, and yoshimuraite, Ba4Ti4+2Mn4(Si2O7)2(PO4)2O2(OH)2. The Canadian Mineralogist, 52 (3) 569-576 doi:10.3749/canmin.52.3.569DOI: 10.3749/canmin.52.3.569
  4. 2017(2017) Ferroericssonite. Handbook of Mineralogy. Mineralogical Society of America
