Ferruccite

NaBF4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fru
Discovered
1933
Also known as
  • Ferrucciet

Where it forms, where it's found

Geological setting

Active volcanic fumaroles.

Type locality
Mount Vesuvius
  1. Metropolitan City of Naples
  2. Campania
  3. Italy
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colourless to white
Cleavage
Distinct/Good

On (100), (010), and (001).

Density
2.496 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 11° · 2V calc = 22°
Refractive index
1.301 – 1.3068
Surface relief
Low
Principal indices
nα 1.301 · nβ 1.3012 · nγ 1.3068
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0058
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]58 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation58 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmcm
Cell parameters
a = 6.82 Å · b = 6.25 Å · c = 6.77 Å
Ratio a:b:c
1 : 0.916 : 0.993
Z
4
Morphology

Artificial crystals tabular (001) or (010) with c(001), a(100), b(010), and m(110).

Comment

Synthetic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
9FFluorineFluorine418.99875.992
69.21%
11NaSodiumSodium122.99022.990
20.94%
5BBoronBoron110.81010.810
9.85%
Total109.792100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferrucciet

In other languages

German
Ferruccit
Italian
Ferruccite

Classification

Strunz
10th ed.

3.CA.05

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.CABorofluoridesGroup
  • 3.CA.05FerrucciteSpecies
Dana
8th ed.

11.02.03.01

  • 11Halide ComplexesClass
  • 11.02AmBX4Type
  • 11.02.03— unnamed intermediate level —Group
  • 11.02.03.01FerrucciteSpecies
CIM

8.12.1

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.12— unnamed intermediate level —Group
  • 8.12.1FerrucciteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1933Carobbi, G. (1933) Sulla presenza di un nuova minerale fra i prodotti dell’attività fumarolica del Vesuvio. Periodico di Mineralogia-Roma: 4: 410-422.
  2. 1934Foshag, W.F. (1934) New mineral names. American Mineralogist: 19: 555-556.
  3. 1936Finbak, Hassel (1936) Zeitschrift für Physikalische Chemie, Leipzig, Berlin: 32: 433.
  4. 1937Klinkenberg (1937) Recueil des travaux chimiques des Pays-Bas et de la Belgique, Leyden: 56: 36.
  5. 1946Bellanca (1946) Rendus Soc. Min. Ital.: 3: 20.
