Fiedlerite

Pb3Cl4F(OH) · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fie
Discovered
1887
Also known as
  • Fiedleriet

Where it forms, where it's found

Type locality
Lavrion Slag Localities
  1. Lavreotiki
  2. East Attica
  3. Attica
  4. Greece
21recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · white · colourless in transmitted light.
Cleavage
Distinct/Good

On (100).

Density
5.88 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.98 – 2.1
Surface relief
Very high
Principal indices
nα 1.98 · nβ 2.04 · nγ 2.1
Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.1200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1200 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1200 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 16.68 Å · b = 8.04 Å · c = 7.28 Å
Cell angles
β = 102.56 °
Ratio a:b:c
1 : 0.482 : 0.436
Morphology

Crystals lath-like; tabular (100) and elongated [010] with a rectangular outline. Crystal faces normally of poor quality. Forms include a(100), c(001), m(110), n(650), d(101), x(101), y(201), e(154) and o(554).

Twinning

On (100), common.

Type-locality form

Thin tablets.

Comment

Data for 2M polytype. Data for 1A polytype (Zubkova et al., 2019): a = 8.5741(7), b = 8.0480(5), с = 7.2695(4), α = 90.087(5), β = 102.126(6), γ = 103.424(6); V = 476.37(6), Z = 2.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
76.04%
17ClChlorineChlorine435.450141.800
17.35%
8OOxygenOxygen215.99931.998
3.92%
9FFluorineFluorine118.99818.998
2.32%
1HHydrogenHydrogen31.0083.024
0.37%
Total817.420100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fiedleriet

In other languages

French
Fiedlérite · Fieldérite
German
Fiedlerit
Spanish
Fiedlerita
Italian
Fiedlerite

Classification

Strunz
10th ed.

3.DC.10

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DCWith Pb (As,Sb,Bi), without CuGroup
  • 3.DC.10FiedleriteSpecies
Dana
8th ed.

10.03.02.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.03A3(O,OH)2XqType
  • 10.03.02— unnamed intermediate level —Group
  • 10.03.02.01FiedleriteSpecies
CIM

8.8.10

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.8Halides of PbGroup
  • 8.8.10FiedleriteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1887vom Rath, G. (1887) Berichte Niederrheinische Gesellschaft für Natur und Heilkunde, Bonn: 154.
  2. 1887vom Rath, G. (1887) Einige mineralogische und geologische Mittheilungen. Niederheinische Gesellschafte für Natur und Theilkunde, Bonn: 102: 149-154.
  3. 1889vom Rath, G. (1889) Neues Jahrbuch für Mineralogie, Geologie und Paleontologie, Heidelberg, Stuttgart: I: 388.
  4. 1899Herbert Smith, G. F., Prior, G. T. (1899) On some lead minerals from Laurium, namely, Laurionite, Phosgenite, Fiedlerite, and (new species) Paralaurionite. Mineralogical Magazine and Journal of the Mineralogical Society, 12 (55) 102-110 doi:10.1180/minmag.1899.012.55.06 DOI: 10.1180/minmag.1899.012.55.06
  5. 1905de Schulten, A. (1905) Sur la fiedlerite. Comptes rendus de l’Académie des sciences de Paris: 140: 315-316.
