Filipstadite

(Fe3+0.5Sb5+0.5)Mn2+2O4
IMA status
  • Approved
IMA symbol
Fps
Discovered
1988
Also known as
  • Filipstadiet
  • IMA1987-010

Where it forms, where it's found

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Brown
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
4.9 g/cm³

Optical

Optical type
Biaxial
Dispersion
r > v strong
Optical colour
gray
Anisotropism
Weak; in shades of dark brownish gray
Internal reflections
amber-orange, brown, or red
Tropism
Anisotropic
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Cell parameters
a = 25.9300 Å · b = 25.9300 Å · c = 25.9300 Å
Ratio a:b:c
1 : 1.000 : 1.000
Z
216
Morphology

Euhedral to subhedral equant crystals up to 200 micron

Twinning

Poorly developed sector twinning evident in reflected light

Type-locality form

As euhedral equant crystals up to 200 mikron in diameter and aggregates

Comment

Orthorhombic, pseudocubic. Point Group: n.d.; Space Group: n.d.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese254.938109.876
41.83%
8OOxygenOxygen415.99963.996
24.36%
51SbAntimonyAntimony0.5121.76060.880
23.18%
26FeIronIron0.555.84527.922
10.63%
Total262.675100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Filipstadiet
  • IMA1987-010

In other languages

German
Filipstadit · IMA1987-010
Italian
Filipstadite
Portuguese
Filipstadita · IMA1987-010

Classification

Strunz
10th ed.

4.BB.05

  • 4OxidesClass
  • 4.BMetal: Oxygen = 3:4 and similarDivision
  • 4.BBWith only medium-sized cationsGroup
  • 4.BB.05FilipstaditeSpecies
Dana
8th ed.

07.02.13.01

  • 07Multiple OxidesClass
  • 07.02AB2X4Type
  • 07.02.13— unnamed intermediate level —Group
  • 07.02.13.01FilipstaditeSpecies
CIM

7.19.6

  • 7Oxides and HydroxidesClass
  • 7.19Oxides of Mn and FeGroup
  • 7.19.6FilipstaditeSpecies

Group, growth & confusion

In the same group
6 members

Literature, links & citation

Citations
  1. 1988Dunn, Pete J., Peacor, Donald R., Criddle, Alan J., Stanley, Chris J. (1988) Filipstadite, a new Mn-Fe3+-Sb derivative of spinel, from Långban, Sweden. American Mineralogist, 73 (3-4) 413-419
  2. 2005(2005) Filipstadite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2013Bonazzi, P., Chelazzi, L., Bindi, L. (2013) Superstructure, crystal chemistry, and cation distribution in filipstadite, a Sb5+-bearing, spinel-related mineral. American Mineralogist, 98 (2) 361-366 doi:10.2138/am.2013.4259DOI: 10.2138/am.2013.4259
  4. 2019Bosi, Ferdinando, Biagioni, Cristian, Pasero, Marco (2019) Nomenclature and classification of the spinel supergroup. European Journal of Mineralogy, 31 (1) 183-192 doi:10.1127/ejm/2019/0031-2788 DOI: 10.1127/ejm/2019/0031-2788
