Ringwoodite

SiMg2O4
IMA status
  • Approved
IMA symbol
Rwd
Discovered
1969
IMA approved
1968
Also known as
  • IMA1968-036
  • Ringwoodiet

Where it forms, where it's found

Geological setting

Tenham meteorite

Meteorites, Inclusion in terrestrial diamond

Type locality
Tenham meteorite
  1. Tenham Station
  2. Windorah
  3. Barcoo Shire
  4. Queensland
  5. Australia

-25.7333°, 142.9500°

31recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Translucent
Colour
Bluish- to smoke-gray · purple · colourless
Density
3.9 g/cm³

Optical

Optical type
Isotropic
Surface relief
High
Principal indices
n 1.768
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.768

Crystallography

Crystal system
Isometric
Space group
Fd-3m
Cell parameters
a = 8.113 Å
Z
8
Morphology

Rounded grains, to 100 μm, or massive

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
45.49%
12MgMagnesiumMagnesium224.30548.610
34.55%
14SiSiliconSilicon128.08528.085
19.96%
Total140.691100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mn
  • Ca

Synonyms

  • IMA1968-036
  • Ringwoodiet

In other languages

French
ringwoodite
German
IMA 1968-036 · Ringwoodit
Spanish
Ringwoodita
Italian
Ringwoodite
Portuguese
ringwoodita
Japanese
リングウッダイト
Chinese
尖晶橄榄石
Russian
Рингвудит
Arabic
رينغووديت

Classification

Strunz
10th ed.

9.AC.15

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ACNesosilicates without additional anions; cations in octahedral [6] coordinationGroup
  • 9.AC.15RingwooditeSpecies
Dana
8th ed.

51.03.03.01

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.03Insular SiO4 Groups Only with all cations in octahedral [6] coordinationType
  • 51.03.03— unnamed intermediate level —Group
  • 51.03.03.01RingwooditeSpecies
CIM

14.21.2

  • 14Silicates not Containing AluminumClass
  • 14.21Silicates of Fe and MgGroup
  • 14.21.2RingwooditeSpecies

Group, growth & confusion

In the same group
6 members
Commonly confused with
4 minerals

Literature, links & citation

Citations
  1. 1969Fleischer, Michael (1969) New Mineral Names. American Mineralogist, 54 (7-8) 1218-1223
  2. 1969Binns, R. A., Davis, R. J., Reed, S. J. B. (1969) Ringwoodite, Natural (Mg,Fe)2SiO4 Spinel in the Tenham Meteorite. Nature, 221 (5184) 943-944 doi:10.1038/221943a0DOI: 10.1038/221943a0
  3. 1977Coleman, L. C. (1977) Ringwoodite and majorite in the Catherwood meteorite. The Canadian Mineralogist, 15 (1) 97-101
  4. 1982Boctor, N. Z., Bell, P. M., Mao, H. K., Kullerud, G. (1982) Petrology and shock metamorphism of Pampa del Infierno chondrite. Geochimica et Cosmochimica Acta, 46 (10) 1903-1911 doi:10.1016/0016-7037(82)90128-4DOI: 10.1016/0016-7037(82)90128-4
  5. 1998Sinogeikin, S. V., Katsura, T., Bass, J. D. (1998) Sound velocities and elastic properties of Fe-bearing wadsleyite and ringwoodite. Journal of Geophysical Research: Solid Earth, 103. 20819-20825 doi:10.1029/98jb01819DOI: 10.1029/98jb01819
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Ringwoodite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/ringwoodite-3421},
  note      = {Accessed 2026-05-11}
}
