Fluellite

Al2(PO4)F2(OH) · 7H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fll
Discovered
1824
Also known as
  • Fluate of Alumine
  • Fluelliet
  • Fluoride of Aluminum
  • +4 more

Where it forms, where it's found

Geological setting

In pegmatites

Type locality
Stenna Gwyn Mine (Stennagwyn Mine)
  1. Foxhole
  2. St Stephen-in-Brannel
  3. Cornwall
  4. England
  5. UK

50.3614°, -4.8656°

44recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless · white · yellow
Streak
White
Cleavage
Poor/Indistinct

On (010) and (111).

Density
2.139 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.473 – 1.511
Surface relief
Low
Principal indices
nα 1.473 – 1.49 · nβ 1.49 – 1.496 · nγ 1.506 – 1.511
Dispersion
none
UV response
May fluoresce creamy white under SW, MW and LW (Harold Moritz comm., 2022).
Michel-Lévy diagramhighlighted lineδ = 0.0270
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]270 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation270 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#53
Cell parameters
a = 11.22 Å · b = 21.15 Å · c = 8.54 Å
Ratio a:b:c
1 : 1.885 : 0.761
Morphology

Crystals dipyramidal (111), often modified by (010).

Type-locality form

Transparent acute rhombic octahedrons

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
58.17%
13AlAluminiumAluminium226.98253.964
16.35%
9FFluorineFluorine218.99837.996
11.51%
15PPhosphorusPhosphorus130.97430.974
9.39%
1HHydrogenHydrogen151.00815.120
4.58%
Total330.042100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluate of Alumine
  • Fluelliet
  • Fluoride of Aluminum
  • Kreuzbergit
  • Kreuzbergita
  • Kreuzbergite
  • Pleysteinite (of Groth)

In other languages

German
Fluellit
Spanish
Fluelita · Fluellita
Italian
Fluellite

Classification

Strunz
10th ed.

8.DE.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DEWith only medium-sized cations, (OH, etc.):RO4 = 3:1Group
  • 8.DE.10FluelliteSpecies
Dana
8th ed.

42.06.09.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.06A2(XO4)Zq·xH2OType
  • 42.06.09— unnamed intermediate level —Group
  • 42.06.09.01FluelliteSpecies
CIM

22.1.14

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.1Phosphates, arsenates or vanadates with fluorideGroup
  • 22.1.14FluelliteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1824Levy, A. (1824) On a new mineral substance. The Annals of Philosophy: 8: 241-245 (242-243).
  2. 1915Laubmann, H.; Steinmetz, H. (1915) Phosphatführende Pegmatite des Oberpfälzer und Bayerischen Waldes. Zeitschrift für Kristallographie, Mineralogie und Petrographie, 55 (1-6). 523-586 doi:10.1524/zkri.1915.55.1.523DOI: 10.1524/zkri.1915.55.1.523
  3. 1916Groth (1916) Zeitschrift für praktische Geologie, 24: 190 (as Pleysteinite).
  4. 1940Scholz and Strunz (1940) Centralblatt für Mineralogie, Geologie und Paleontologie, Stuttgart: 133.
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
