Metavariscite

Al(PO4) · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mvar
Discovered
1925
Also known as
  • Metavarisciet

Where it forms, where it's found

Geological setting

Sedimentary phosphate mineralization along fractures

Phosphate-rich veins, sedimentary phosphates deposits, guano deposits

Type locality
Edison Bird Mine
  1. Utahlite Hill
  2. Lucin
  3. Box Elder County
  4. Utah
  5. USA

41.4004°, -113.8803°

24recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light green · colourless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (010).

Density
2.51 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 55° · 2V calc = 58°
Refractive index
1.551 – 1.582
Surface relief
Moderate
Principal indices
nα 1.551 · nβ 1.558 · nγ 1.582
Birefringence
0.031
Pleochroism
Weak

X = colorless, Y = Z = light green

Dispersion
r < v strong
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0310
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]310 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation310 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 5.18 Å · b = 9.51 Å · c = 8.45 Å
Cell angles
β = 90.4 °
Ratio a:b:c
1 : 1.836 : 1.631
Morphology

Crystals thin to thick tabular (010), equant or slightly elongated [001] or [100], yielding lath-like forms; long prismatic [100] rare. Form development is markedly pseudo-orthorhombic. Also occurs as loosely coherent granular masses.

Twinning

On (102), as contact twins.

Comment

P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
60.76%
15PPhosphorusPhosphorus130.97430.974
19.61%
13AlAluminiumAluminium126.98226.982
17.08%
1HHydrogenHydrogen41.0084.032
2.55%
Total157.982100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Metavarisciet

In other languages

German
Clinovariscit · Metavariscit
Italian
Metavariscite

Classification

Strunz
10th ed.

8.CD.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CDWith only medium-sized cations, RO4:H2O = 1:2Group
  • 8.CD.05MetavarisciteSpecies
Dana
8th ed.

40.04.03.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.04(AB)5(XO4)2·xH2OType
  • 40.04.03Metavariscite groupGroup
  • 40.04.03.01MetavarisciteSpecies
CIM

19.7.6

  • 19PhosphatesClass
  • 19.7Phosphates of Al aloneGroup
  • 19.7.6MetavarisciteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1912Schaller (1912) USGS Bull. 509: 48 (as Variscite).
  2. 1916Schaller (1916) UGS Bull. 610: 69 (as Variscite).
  3. 1925Larsen, Esper S., Schaller, Waldemar T. (1925) The identity of variscite and peganite and the dimorphous form metavariscite. American Mineralogist, 10 (2). 23-28
  4. 1930Ulrich (1930) Rozpr. České Ak., Cl. 2, 39, no. 17.
  5. 1939Strunz and Sztrókay (1939) Zentralblatt Mineralien: 272.
