Fluorcaphite

SrCaCa3(PO4)3F
IMA status
  • Approved
IMA symbol
Fcp
IMA approved
1996
Also known as
  • Fluorcaphiet
  • Fluorcaphita
  • IMA1996-022

Where it forms, where it's found

Geological setting

In miarolitic cavities in the central part of a hyperagpaitic pegmatite in ijolite-urtite.

Type locality
Koashva Open Pit
  1. Koashva Mt
  2. Murmansk Oblast
  3. Russia

67.6167°, 34.0000°

10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Bright yellow
Tenacity
brittle
Density
3.60 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.637 – 1.649
Surface relief
Moderate
Principal indices
nω 1.649 · nε 1.637
Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#108
Cell parameters
a = 9.485(3) Å · c = 7.000(3) Å
Z
2
Type-locality form

Subhedral prisms up to 5 mm long, and in aggregates up to 15 mm across.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
34.79%
20CaCalciumCalcium440.078160.312
29.05%
15PPhosphorusPhosphorus330.97492.922
16.84%
38SrStrontiumStrontium187.62087.620
15.88%
9FFluorineFluorine118.99818.998
3.44%
Total551.840100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluorcaphiet
  • Fluorcaphita
  • IMA1996-022

In other languages

French
fluorcaphite
German
Fluorcaphit · IMA 1996-022
Italian
Fluorcafite · Fluorcaphite

Classification

Strunz
10th ed.

8.BN.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BNWith only large cations, (OH, etc.):RO4 = 0.33:1Group
  • 8.BN.05FluorcaphiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1997Khomyakov, A. P., Kulikova, I. M., Rastsvetaeva, R. K. (1997) Fluorcaphite Ca(Sr,Na,Ca)(Ca,Sr,Ce)3(PO4)3F – a new mineral with the apatite structural motif. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 126 (3) 87-97
  2. 1998Mandarino, Joseph A. (1998) Abstracts of New Mineral Descriptions. The Mineralogical Record, 29 (5) 467-479
  3. 1998Jambor, J.L., Pertsev, N.N., Roberts, A.C. (1998) New mineral names. American Mineralogist: 83: 907-911.
  4. 2005(2005) Fluorcaphite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2017Kropáč, Kamil, Dolníček, Zdeněk, Uher, Pavel, Urubek, Tomáš (2017) Fluorcaphite from hydrothermally altered teschenite at Tichá, Outer Western Carpathians, Czech Republic: compositional variations and origin. Mineralogical Magazine, 81 (6) 1485-1501 doi:10.1180/minmag.2017.081.016DOI: 10.1180/minmag.2017.081.016
