Fukuchilite

Cu3FeS8
IMA status
  • Approved
IMA symbol
Fuk
Discovered
1969
Also known as
  • Fukuchiliet
  • IMA1967-009

Where it forms, where it's found

Type locality
Hanawa mine
  1. Kazuno City
  2. Akita Prefecture
  3. Japan

40.1669°, 140.8328°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Dark brownish gray
Density
4.86 g/cm³

Optical

Optical colour
Pinkish brown
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Space group
#204
Cell parameters
a = 5.58 Å
Z
1
Morphology

Eutectic intergrowth with pyrite and covellite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
16SSulfurSulfur832.060256.480
51.00%
29CuCopperCopper363.546190.638
37.90%
26FeIronIron155.84555.845
11.10%
Total502.963100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fukuchiliet
  • IMA1967-009

In other languages

French
Fukuchilite
German
Fukuchilit · IMA1967-009
Italian
Fukuchilite
Japanese
福地鉱
Chinese
硫铁铜矿

Classification

Strunz
10th ed.

2.EB.05a

  • 2Sulfides and SulfosaltsClass
  • 2.EMetal Sulfides, M: S <= 1:2Division
  • 2.EBM:S = 1:2, with Fe, Co, Ni, PGE, etc.Group
  • 2.EB.05aFukuchiliteSpecies
Dana
8th ed.

02.12.01.07

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.01Pyrite Group (Isometric: Pa3)Group
  • 02.12.01.07FukuchiliteSpecies
CIM

3.1.24

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.1Sulphides etc. of CuGroup
  • 3.1.24FukuchiliteSpecies

Group, growth & confusion

In the same group
16 members

Literature, links & citation

Citations
  1. 1969KAJIWARA, YOSHIMICHI (1969) Fukuchilite, Cu3FeS8, a new mineral from the Hanawa mine, Akita Prefecture, Japan. Mineralogical Journal, 5 (6). 399-416 doi:10.2465/minerj1953.5.399 DOI: 10.2465/minerj1953.5.399
  2. 1970Fleischer, M., Nickel, E.H. (1970) New mineral names. American Mineralogist: 55: 1810-1818.
  3. 1970Shimazaki, H., Clark, L.A. (1970) Synthetic FeS2-CuS2 solid solution and fukuchilite-like minerals. The Canadian Mineralogist: 10: 648-664.
  4. 1989Bayliss, Peter (1989) Crystal chemistry and crystallography of some minerals within the pyrite group. American Mineralogist, 74 (9-10) 1168-1176
  5. 1993Schmid-Beurmann, Peter, Lottermoser, Werner (1993) 57Fe-Moessbauer spectra, electronic and crystal structure of members of the CuS2-FeS2 solid solution series. Physics and Chemistry of Minerals, 19 (8) doi:10.1007/bf00203056DOI: 10.1007/bf00203056
