Garronite-Ca

Ca3(Al6Si10O32) · 14H2O
IMA status
  • Approved
IMA symbol
Grn-Ca
Discovered
1960
Also known as
  • Garroniet-Ca
  • Garronita

Where it forms, where it's found

Geological setting

In amygdales in basalt

Type locality
Glenariff Valley
  1. Garron Plateau
  2. County Antrim
  3. Northern Ireland
  4. UK

55.0322°, -6.0794°

67recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
White
Streak
White
Cleavage

Two cleavages at about 90°, both parallel to the length of the individuals

Density
2.13 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.5 – 1.515
Surface relief
Moderate
Principal indices
nβ 1.5 – 1.515
Dispersion
none

Crystallography

Crystal system
Tetragonal
Space group
#144
Cell parameters
a = 9.9266(2) Å · c = 10.3031(3) Å
Morphology

Radiating aggregates filling voids. Rarely dipyramidal, indistinct crystals.

Twinning

Observed optically on a very fine scale; possibly a domain structure.

Type-locality form

Radiating aggregates completely filling amygdales, to 2 cm.

Comment

Z = 0.5. Possibly orthorhombic, pseudo-tetragonal.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4615.999735.954
55.45%
14SiSiliconSilicon1028.085280.850
21.16%
13AlAluminiumAluminium626.982161.892
12.20%
20CaCalciumCalcium340.078120.234
9.06%
1HHydrogenHydrogen281.00828.224
2.13%
Total1327.154100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ba
  • K

Synonyms

  • Garroniet-Ca
  • Garronita

In other languages

German
Garronit-Ca
Spanish
Garronita-Ca
Italian
garronite-Ca

Classification

Strunz
10th ed.

9.GC.05

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GCChains of doubly-connected 4-membered ringsGroup
  • 9.GC.05Garronite-CaSpecies
Dana
8th ed.

77.01.03.03

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.03Gismondine and related speciesGroup
  • 77.01.03.03Garronite-CaSpecies
CIM

16.10.8

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.10Aluminosilicates of Ca and alkalisGroup
  • 16.10.8Garronite-CaSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1962Walker, G. P. L. (1962) Garronite, a new zeolite, from Ireland and Iceland. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (258). 173-186 doi:10.1180/minmag.1962.033.258.01 DOI: 10.1180/minmag.1962.033.258.01
  2. 1983Nawaz, Rab (1983) New data on gobbinsite and garronite. Mineralogical Magazine, 47 (345) 567-568 doi:10.1180/minmag.1983.047.345.20DOI: 10.1180/minmag.1983.047.345.20
  3. 1992Artioli, G. (1992) The crystal structure of garronite. American Mineralogist, 77 (1-2) 189-196
  4. 1994Howard, Donald G. (1994) Crystal habit and twinning of garronite from Fara Vicentina, Vicenza (Italy). Neues Jahrbuch für Mineralogie - Monatshefte, 1994 (2). 91-96 doi:10.1127/njmm/1994/1994/91DOI: 10.1127/njmm/1994/1994/91
  5. 1999Artioli, Gilberto; Marchi, Maurizio (1999) On the space group of garronite. Powder Diffraction, 14 (3). 190-194 doi:10.1017/s0885715600010514DOI: 10.1017/s0885715600010514
