Gjerdingenite-Mn

K2Mn(Nb,Ti)4(Si4O12)2(O,OH)4 · 6H2O
IMA status
  • Approved
IMA symbol
Gje-Mn
Discovered
2002
IMA approved
2003
Also known as
  • Gjerdingeniet-Mn
  • IMA2003-015

Where it forms, where it's found

Geological setting

In miarolitic cavities in a permian sodic granite (ekerite).

Type locality
Gjerdingselva
  1. Lunner
  2. Akershus
  3. Norway

60.1840°, 10.6481°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale yellowish to tan
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.93 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 52° · 2V calc = 46°
Refractive index
1.67 – 1.775
Surface relief
High
Principal indices
nα 1.670 · nβ 1.685 · nγ 1.775
Pleochroism
Visible

Y = yellowish brown; X = Z = colorless

Dispersion
Weak, r < v
Extinction
Z = a, Y = b
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.1050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1050 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1050 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.563 Å · b = 13.961 Å · c = 7.851 Å
Cell angles
α = 117.62 °
Ratio a:b:c
1 : 0.959 : 0.539
Unit cell volume
1414.3 ų
Z
2
Morphology

Prismatic on [010]; with forms (001), (100), (201) and (021).

Twinning

On (001)

Type-locality form

Rod-like crystals and groups.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3815.999607.962
39.35%
41NbNiobiumNiobium492.906371.624
24.05%
14SiSiliconSilicon828.085224.680
14.54%
22TiTitaniumTitanium447.867191.468
12.39%
19KPotassiumPotassium239.09878.196
5.06%
25MnManganeseManganese154.93854.938
3.56%
1HHydrogenHydrogen161.00816.128
1.05%
Total1544.996100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • Fe

Synonyms

  • Gjerdingeniet-Mn
  • IMA2003-015

In other languages

German
Gjerdingenit-Mn · IMA 2003-015
Italian
gjerdingenite-Mn

Classification

Strunz
10th ed.

9.CE.30c

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.30cGjerdingenite-MnSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2004Raade, Gunnar, Chukanov, Nikita V., Kolitsch, Uwe, Möckel, Steffen, Zadov, Aleksandr E., Pekov, Igor V. (2004) Gjerdingenite-Mn from Norway a new mineral species in the labuntsovite group: descriptive data and crystal structure. European Journal of Mineralogy, 16 (6) 979-987 doi:10.1127/0935-1221/2004/0016-0979 DOI: 10.1127/0935-1221/2004/0016-0979
  2. 2005Piilonen, P. C. (2005) New mineral names. American Mineralogist, 90 (7) 1227-1232 doi:10.2138/am.2005.445DOI: 10.2138/am.2005.445
  3. 2014(2014) Gjerdingenite-Mn. Handbook of Mineralogy. Mineralogical Society of America
