Gmelinite-Ca

Ca2(Si8Al4)O24 · 11H2O
IMA status
  • Approved
IMA symbol
Gme-Ca
Also known as
  • Gmeliniet-Ca

Where it forms, where it's found

Type locality
Monte Nero
  1. San Pietro
  2. Montecchio Maggiore
  3. Vicenza Province
  4. Veneto
  5. Italy

45.5082°, 11.4194°

22recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Dull
Transparency
Transparent · Translucent
Colour
Colorless · white · pink
Streak
White
Tenacity
brittle
Fracture
Irregular/Uneven
Density
2.11 g/cm³

Optical

Optical type
Uniaxial (+/-)
Refractive index
1.477 – 1.485
Surface relief
Low
Principal indices
nω 1.485 · nε 1.477
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 13.800(5) Å · c = 9.964(5) Å
Z
4
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3515.999559.965
56.28%
14SiSiliconSilicon828.085224.680
22.58%
13AlAluminiumAluminium426.982107.928
10.85%
20CaCalciumCalcium240.07880.156
8.06%
1HHydrogenHydrogen221.00822.176
2.23%
Total994.905100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gmeliniet-Ca

In other languages

German
Gmelinit-Ca
Italian
gmelinite-Ca

Classification

Strunz
10th ed.

9.GD.05

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.05Gmelinite-CaSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1867Marsh, Othniel Charles (1867) Contributions to the Mineralogy of Nova Scotia, No. 1 - Ledererite identical with Gmelinite. American Journal of Science and Arts, S. 2 Vol. 44. 362-367
  2. 1978Passaglia, E., Pongiluppi, D., Vezzalini, G. (1978) The crystal chemistry of gmelinites. Neues Jahrbuch für Mineralogie, Monatshefte, 1978. 310-324
  3. 1982Fischer, K. (1982) Untersuchung der Kristallstruktur von Gmelinit. Neues Jahrbuch für Mineralogie, Monatshefte, 1982. 1-13
  4. 1982Galli, E., Zanazzi, P. F. (1982) Gmelinite: structural refinements of sodium-rich and calcium-rich natural crystals. Neues Jahrbuch für Mineralogie, Monatshefte, 1982. 145-155
  5. 1995Sacerdoti, M., Passaglia, E., Carnevali, R. (1995) Structural refinements of Na-, K-, and Ca-exchanged gmelinites. Zeolites, 15 (3) 276-281 doi:10.1016/0144-2449(94)00024-mDOI: 10.1016/0144-2449(94)00024-m
