Gmelinite-Na

Na4(Si8Al4)O24 · 11H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gme-Na
Also known as
  • Gmeliniet-Na

Where it forms, where it's found

Geological setting

In basalts and pegmatites.

Type locality
Monte Nero
  1. San Pietro
  2. Montecchio Maggiore
  3. Vicenza Province
  4. Veneto
  5. Italy

45.5082°, 11.4194°

25recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Dull
Transparency
Transparent · Translucent · Opaque
Colour
Colorless · white · reddish white · salmon-red · yellowish · greenish white
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (1010)

Fracture
Irregular/Uneven
Density
2.02 g/cm³

Optical

Optical type
Uniaxial (+/-)
Refractive index
1.474 – 1.494
Surface relief
Low
Principal indices
nω 1.476 – 1.494 · nε 1.474 – 1.48
Notes

May be anomalously biaxial.

Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P63/mmc
Cell parameters
a = 13.78(2) Å · c = 10.03(5) Å
Z
4
Morphology

Pyramidal, tabular, rhombohedral

Twinning

Penetration twins common on (1011)

Parting
(0001)
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3515.999559.965
55.62%
14SiSiliconSilicon828.085224.680
22.32%
13AlAluminiumAluminium426.982107.928
10.72%
11NaSodiumSodium422.99091.960
9.14%
1HHydrogenHydrogen221.00822.176
2.20%
Total1006.709100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gmeliniet-Na

In other languages

German
Gmelinit-Na
Italian
gmelinite-Na
Chinese
钠菱沸石

Classification

Strunz
10th ed.

9.GD.05

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.05Gmelinite-NaSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1876Howe, A. B. (1876) On gmelinite from Nova Scotia. American Journal of Science, S. 3 Vol. 12 (70) 270-274 doi:10.2475/ajs.s3-12.70.270DOI: 10.2475/ajs.s3-12.70.270
  2. 1959Walker, George P. L. (1959) The amygdale minerals in the Tertiary lavas of Ireland. II. The distribution of gmelinite. Mineralogical Magazine and Journal of the Mineralogical Society, 32 (246) 202-217 doi:10.1180/minmag.1959.032.246.03 DOI: 10.1180/minmag.1959.032.246.03
  3. 1978Passaglia, E., Pongiluppi, D., Vezzalini, G. (1978) The crystal chemistry of gmelinites. Neues Jahrbuch für Mineralogie, Monatshefte, 1978. 310-324
  4. 1982Fischer, K. (1982) Untersuchung der Kristallstruktur von Gmelinit. Neues Jahrbuch für Mineralogie, Monatshefte, 1982. 1-13
  5. 1982Galli, E., Zanazzi, P. F. (1982) Gmelinite: structural refinements of sodium-rich and calcium-rich natural crystals. Neues Jahrbuch für Mineralogie, Monatshefte, 1982. 145-155
