Gysinite-(Ce)

PbCe(CO3)2(OH)·H2O
IMA status
  • Approved
IMA symbol
Gys-Ce
IMA approved
2023
Also known as
  • Gysiniet-(Ce)

Where it forms, where it's found

Geological setting

It is a secondary oxidation-zone mineral presumably crystallized from hydrothermal solutions

Type locality
Abendröthe Mine
  1. St Andreasberg
  2. Braunlage
  3. Goslar District
  4. Lower Saxony
  5. Germany

51.7095°, 10.5211°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
brownish yellow
Streak
pale yellow
Tenacity
brittle
Cleavage
None Observed

curved, irregular fracture

Fracture
Irregular/Uneven
Density
5.136 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 65.1°
Refractive index
1.75 – 1.86
Surface relief
Very high
Principal indices
nα 1.750 · nβ 1.825 · nγ 1.860
Pleochroism
Non-pleochroic
Dispersion
no observable dispersion.
Michel-Lévy diagramhighlighted lineδ = 0.1100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1100 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1100 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 5.0780(4) Å · b = 8.6689(6) Å · c = 7.3255(6) Å
Ratio a:b:c
1 : 1.707 : 1.443
Z
2
Type-locality form

occurs in intergrowths of equant pseudo-octahedral crystals, up to about 0.7 mm in maximum dimension.

Comment

the space group is Pmcn

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
41.25%
58CeCeriumCerium1140.116140.116
27.89%
8OOxygenOxygen815.999127.992
25.48%
6CCarbonCarbon212.01124.022
4.78%
1HHydrogenHydrogen31.0083.024
0.60%
Total502.354100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Gysiniet-(Ce)

In other languages

German
Gysinit-(Ce) · IMA 2023-035

Classification

Strunz
10th ed.

5.DC

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DCWith large cationsGroup
  • 5.DCGysinite-(Ce)Species

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 2023Bosi, Ferdinando; Hatert, Frédéric; Pasero, Marco; Mills, Stuart J. (2023) Newsletter 74. Mineralogical Magazine, 87 (5). 783-787 doi:10.1180/mgm.2023.54DOI: 10.1180/mgm.2023.54
  2. 2024Kampf, Anthony R.; Möhn, Gerhard; Ma, Chi; Désor, Joy; Groß, Manfred (2024) Gysinite-(Ce), PbCe(CO3)2(OH)(H2O), a New Member of the Ancylite Group. The Canadian Journal of Mineralogy and Petrology. doi:10.3749/2400015DOI: 10.3749/2400015
