Haiweeite

Ca(UO2)2(Si5O12)(OH)2 · 6H2O
IMA status
  • Approved
IMA symbol
Hwe
Discovered
1959
Also known as
  • Gastunite
  • Haiweeiet
  • Ranquilit
  • +2 more

Where it forms, where it's found

Type locality
Unnamed U occurrence [1]
  1. Inyo County
  2. California
  3. USA

36.1369°, -117.9500°

19recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Pearly
Transparency
Translucent
Colour
Pale yellow · greenish-yellow
Streak
White
Cleavage
Distinct/Good

On (100)

Density
3.35 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 15° · 2V calc = 46 – 50°
Refractive index
1.56 – 1.582
Surface relief
Moderate
Principal indices
nα 1.56 – 1.571 · nβ 1.575 – 1.58 · nγ 1.578 – 1.582
Pleochroism

Y = pale yellow; Z = colorless. Y = b.

Dispersion
r > v strong
UV response
Weak dull-green
Michel-Lévy diagramhighlighted lineδ = 0.0145
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]145 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation145 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pbcn
Cell parameters
a = 18.3000(5) Å · b = 14.2331(3) Å · c = 17.9192(5) Å
Ratio a:b:c
1 : 0.778 : 0.979
Z
8
Type-locality form

Spherulitic aggregates, or single flakelike grains, on fracture surfaces in granite.

Comment

Crystal from Teofilo Otoni, Minas Gerais, Brazil

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
45.14%
8OOxygenOxygen2415.999383.976
36.41%
14SiSiliconSilicon528.085140.425
13.31%
20CaCalciumCalcium140.07840.078
3.80%
1HHydrogenHydrogen141.00814.112
1.34%
Total1054.649100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gastunite
  • Haiweeiet
  • Ranquilit
  • Ranquilita
  • Ranquilite

In other languages

German
Haiweeit
Spanish
Haiweeita · Ranquilita
Italian
Haiweeite

Classification

Strunz
10th ed.

9.AK.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AKUranyl neso- and polysilicatesGroup
  • 9.AK.25HaiweeiteSpecies
Dana
8th ed.

53.03.02.02

  • 53Nesosilicates Insular Sio4 Groups and Other Anions or Complex CationsClass
  • 53.03Insular SiO4 Groups and Other Anions of Complex Cations with (UO2)Type
  • 53.03.02Weeksite groupGroup
  • 53.03.02.02HaiweeiteSpecies
CIM

14.16.12

  • 14Silicates not Containing AluminumClass
  • 14.16Silicates of UGroup
  • 14.16.12HaiweeiteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1959McBurney, T. C., Murdoch, J. (1959) Haiweeite, a new uranium mineral from California. American Mineralogist, 44 (7-8) 839-843
  2. 1960Fleischer, M.; Chao, E.C.T. (1960) New mineral names. American Mineralogist, 45 (5-6). 753-756
  3. 1962(1962) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (258) 260-263 doi:10.1180/minmag.1962.033.258.09 DOI: 10.1180/minmag.1962.033.258.09
  4. 1969de Carmargo, William G. R., Svisero, Darcy P. (1969) Haiweeite, a new occurrence in Brazil. American Mineralogist, 54 (5-6). 966-969
  5. 1977Yeremenko, G.K., Il'menov, Ye.S., Azimi, N.A. (1977) Find of weeksite-group minerals in Afghanistan. Doklady Akademii Nauk SSSR Earth Science Sections: 237: 226-228.
