Hawthorneite

BaMgTi3Cr4Fe2+2Fe3+2O19
IMA status
  • Approved
IMA symbol
Hwt
IMA approved
1988
Also known as
  • Hawthorneiet
  • IMA1988-019

Where it forms, where it's found

Geological setting

Formed during upper-mantle (75–100 km, 900–1100 °C, 20–30 kbar) metasomatism of chromian spinel in peridotite xenoliths in a kimberlite pipe.

Type locality
Bultfontein Mine
  1. KEM JV Mine (Kimberley Ekapa Mining Joint Venture mine
  2. Kimberley Underground mine)
  3. Kimberley
  4. Sol Plaatje Local Municipality
  5. Frances Baard District Municipality
  6. Northern Cape
  7. South Africa

-28.7682°, 24.7921°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Black or brown

light gray in reflected light.

Cleavage
None Observed
Density
5.02 g/cm³

Optical

Optical type
Uniaxial (-)
Birefringence
weak to moderate
Pleochroism
Non-pleochroic
Dispersion
r < v
Optical colour
Light gray
Anisotropism
Weak to moderate, brown to gray
Bireflectance
Weakly to moderately bireflectant
Internal reflections
None
Tropism
Anisotropic
Reflectance R%
(18.1,19.5,6.08,7.00) 400, (17.8,19.1,5.79,6.66) 420, (17.5,18.8,5.55,6.36) 440, (17.2,18.4,5.33,6.12) 460, (16.95,18.1,5.18,5.95) 480, (16.9,18.0,5.11,5.87) 490, (16.8,17.9,5.06,5.80) 500, (16.6,17.7,4.98,5.70) 520, (16.5,17.6,4.90,5.61) 540, (16.4,17.5,4.88,5.58) 546, (16.4,17.4,4.83,5.51) 560, (16.3,17.3,4.78,5.45) 580, (16.3,17.3,4.76,5.42) 590, (16.2,17.2,4.75,5.40) 600, (16.15,17.2,4.72,5.37) 620, (16.1,17.1,4.69,5.35) 640, (16.0,17.05,4.68,5.34) 650, (16.0,17.0,4.66,5.32) 660, (15.95,16.95,4.62,5.29) 680, (15.9,16.9,4.58,5.26) 700

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 5.871(2) Å · c = 23.06(2) Å
Z
2
Morphology

grains to 100 µm

Parting
None observed
Type-locality form

Grains, up to 100 µm, surrounded by lindsleyite and oriented in spinel.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1915.999303.981
29.21%
26FeIronIron455.845223.380
21.47%
24CrChromiumChromium451.996207.984
19.99%
22TiTitaniumTitanium347.867143.601
13.80%
56BaBariumBarium1137.327137.327
13.20%
12MgMagnesiumMagnesium124.30524.305
2.33%
Total1040.578100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hawthorneiet
  • IMA1988-019

In other languages

German
Hawthorneit · IMA 1988-019
Italian
Hawthorneite
Chinese
钡钛铁铬矿

Classification

Strunz
10th ed.

4.CC.45

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CCWith large and medium-sized cationsGroup
  • 4.CC.45HawthorneiteSpecies
Dana
8th ed.

07.04.01.03

  • 07Multiple OxidesClass
  • 07.04AB12X19Type
  • 07.04.01(Hexagonal, P63/mmc)Group
  • 07.04.01.03HawthorneiteSpecies
CIM

7.14.9

  • 7Oxides and HydroxidesClass
  • 7.14Oxides of CrGroup
  • 7.14.9HawthorneiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1987Grey, I.E., Madsen, I.C., Haggerty, S.E. (1987) Structure of a new upper-mantle, magnetoplumbite-type phase, Ba[Ti3Cr4Fe4Mg]O19. American Mineralogist: 72: 633-636.
  2. 1989Haggerty, S.E., Grey, I.E., Madsen, I.C., Criddle, A.J., Stanley, C.J., Erlank, A.J. (1989) Hawthorneite, Ba[Ti3Cr4Fe4Mg]O19: a new metasomatic magnetoplumbite-type mineral from the upper mantle. American Mineralogist: 74: 668-675.
  3. 1997Daltry, V. D. C. (1997) Mineralogy of South Africa: Type-Mineral Species and Type-Mineral Names. Handbook 15. Geological Survey of South Africa
  4. 2005(2005) Hawthorneite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2016Anthony, John W., Bideaux, Richard A., Bladh, Kenneth W., Nichols, Monte C. - Eds. (2016) Handbook of Mineralogy. https://www.handbookofmineralogy.org/
