Hercynite

Fe2+Al2O4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hc
Discovered
1847
Also known as
  • Chrysomelane
  • Hercyniet
  • Hercynite (of Zippe)
  • +2 more

Where it forms, where it's found

Type locality
Poběžovice
  1. Domažlice District
  2. Plzeň Region
  3. Czech Republic
390recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark blue-green · yellow · brown
Streak
Dark greyish green to dark green
Tenacity
brittle
Fracture
Conchoidal
Density
4.39 g/cm³

Optical

Optical type
Isotropic
Surface relief
Very high
Principal indices
n 1.80 – 1.83
Pleochroism
Non-pleochroic
Optical colour
Gray
Tropism
Isotropic
Reflectance R%
(8.24,0.70) 400, (8.17,0.67) 420, (8.06,0.66) 440, (7.96,0.65) 460, (7.9,0.64) 470, (7.84,0.64) 480, (7.75,0.63) 500, (7.65,0.62) 520, (7.58,0.61) 540, (7.56,0.61) 546, (7.53,0.60) 560, (7.52,0.61) 580, (7.52,0.60) 589, (7.53,0.61) 600, (7.57,0.62) 620, (7.58,0.62) 640, (7.6,0.62) 650, (7.59,0.62) 660, (7.6,0.63) 680, (7.59,0.63) 700
Notes

Reflectance data for material from Chennimalai, Erode, Coimbatore, India, containing 14.8 wt% MgO (Criddle & Stanley, 1993).

Reflected-light panel
7.7 %anisotropic · dual curve
Specimen sRGB 105, 71, 38
White reference100 % reflector under same lamp
R₁ R₂
Mode
Reflected colour
Gray

Crystallography

Crystal system
Isometric
Space group
#222
Cell parameters
a = 8.119 Å
Z
8
Morphology

Crystals usually octahedral.

Twinning

Common on (111), (spinel law).

Comment

Bowles et al. (2011) summarize results showing cell dimension for synthetic material depends on method of preparation and quenching temperature.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
36.82%
26FeIronIron155.84555.845
32.13%
13AlAluminiumAluminium226.98253.964
31.05%
Total173.805100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chrysomelane
  • Hercyniet
  • Hercynite (of Zippe)
  • Iron Spinel
  • Iron-magnesia Spinel (Synonym)

In other languages

French
Hercynite
German
Hercynit
Spanish
Hercinita · Hercynita
Italian
Hercynite
Japanese
ヘルシナイト
Russian
Герцинит

Classification

Strunz
10th ed.

4.BB.05

  • 4OxidesClass
  • 4.BMetal: Oxygen = 3:4 and similarDivision
  • 4.BBWith only medium-sized cationsGroup
  • 4.BB.05HercyniteSpecies
Dana
8th ed.

07.02.01.03

  • 07Multiple OxidesClass
  • 07.02AB2X4Type
  • 07.02.01(Aluminum subgroup)Group
  • 07.02.01.03HercyniteSpecies
CIM

7.20.14

  • 7Oxides and HydroxidesClass
  • 7.20Oxides of FeGroup
  • 7.20.14HercyniteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. (1971): Neues Jahrbuch für Mineralogie, Abhandlungen: 115: 120-122.
  2. 1839Zippe, F.X.M. (1839) Ueber den Hercinit, eine bisher unbekannt gebliebene Spezies des Mineralreiches. Verhandlungen der Gesellschaft des Vaterländischen Museums in Böhmen: 1839: 19-27.
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1947Verwey, E. J. W., Heilmann, E. L. (1947) Physical Properties and Cation Arrangement of Oxides with Spinel Structures I. Cation Arrangement in Spinels. The Journal of Chemical Physics, 15 (4) 174-180 doi:10.1063/1.1746464DOI: 10.1063/1.1746464
  5. 1984Hill, Roderick J. (1984) X-ray powder diffraction profile refinement of synthetic hercynite. American Mineralogist, 69 (9-10) 937-942
