Hodgkinsonite

Zn2Mn2+(SiO4)(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hgk
Discovered
1913
Also known as
  • Hodgkinsoniet

Where it forms, where it's found

Type locality
Franklin Mine
  1. Franklin
  2. Sussex County
  3. New Jersey
  4. USA

41.1158°, -74.5875°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Bright pink or red to reddish brown and orange · pale pink · rarely yellow · black from tarnishing or inclusions.
Cleavage
Perfect

(011)

Density
4.06 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 50 – 60°
Refractive index
1.72 – 1.746
Surface relief
High
Principal indices
nα 1.720 – 1.724 · nβ 1.741 – 1.742 · nγ 1.746
Pleochroism
Weak

In shades of lavender and pale purple.

Dispersion
r < v moderate
UV response
weak pinkish red in LW UV.
Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 11.761(2) Å · b = 5.316(2) Å · c = 8.171(2) Å
Cell angles
β = 95.25(8) °
Ratio a:b:c
1 : 0.452 : 0.695
Z
4
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc265.380130.760
41.94%
8OOxygenOxygen615.99995.994
30.79%
25MnManganeseManganese154.93854.938
17.62%
14SiSiliconSilicon128.08528.085
9.01%
1HHydrogenHydrogen21.0082.016
0.64%
Total311.793100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg
  • Ca

Synonyms

  • Hodgkinsoniet

In other languages

French
Hodgkinsonite
German
Hodgkinsonit
Italian
Hodgkinsonite
Chinese
硅锰锌矿
Arabic
هودكينسونايت · هودكينسونيت

Classification

Strunz
10th ed.

9.AE.20

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AENesosilicates with additional anions (O,OH,F,H2O); cations in tetrahedral [4] coordinationGroup
  • 9.AE.20HodgkinsoniteSpecies
Dana
8th ed.

52.02.01.03

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.02Insular SiO4 Groups and O, OH, F, and H2O with cations in [4] and >[4] coordinationType
  • 52.02.01Euclase groupGroup
  • 52.02.01.03HodgkinsoniteSpecies
CIM

14.7.20

  • 14Silicates not Containing AluminumClass
  • 14.7Silicates of Ba, Sr and ZnGroup
  • 14.7.20HodgkinsoniteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1913Palache, C., Schaller, W. T. (1913) Hodgkinsonite, a new mineral from Franklin Furnace, New Jersey. Journal of the Washington Academy of Sciences, 3 (19) 474-478
  2. 1914Palache, C.; Schaller, W. T. (1914) Hodgkinsonit, ein neues Mineral von Franklin Furnace, N.J. Zeitschrift für Kristallographie, 53 (1-6). 529-532 doi:10.1524/zkri.1914.53.1.529DOI: 10.1524/zkri.1914.53.1.529
  3. 1962Roberts, W. M. B., Quodling, F. M. (1962) X-ray, optical, and morphological observations on hodgkinsonite from Franklin Furnace. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (259) 343-346 doi:10.1180/minmag.1962.033.259.08 DOI: 10.1180/minmag.1962.033.259.08
  4. 1963Rentzeperis, P. J. (1963) The crystal structure of hodgkinsonite Zn2Mn[(OH)2|SiO4]. Zeitschrift für Kristallographie - Crystalline Materials, 119 (1) 117-138 doi:10.1524/zkri.1963.119.1-2.117 DOI: 10.1524/zkri.1963.119.1-2.117
  5. 1982Dunn, Pete J., Bostwick, Richard C. (1982) Hodgkinsonite from Franklin and Sterling Hill, New Jersey: a Review. The Mineralogical Record, 13 (4) 229-232
