Allactite

Mn2+7(AsO4)2(OH)8
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ala
Discovered
1884
Also known as
  • Allactiet
  • Allactit
  • Allactita
  • +4 more

Where it forms, where it's found

Geological setting

As a rare secondary mineral in veinlets through metamorphosed manganese deposits

in a metamorphosed stratiform zinc orebody (Franklin, New Jersey, USA)

Type locality
Moss mine
  1. Nordmark Odal Field
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8167°, 14.1000°

13recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Greasy
Transparency
Translucent
Colour
Brown · dark to light purplish red · brownish red · colourless to white
Streak
Grayish to faint brown
Tenacity
brittle
Cleavage
Distinct/Good

On (001), distinct.

Fracture
Irregular/Uneven
Density
3.83 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 1° · 2V calc = 36°
Refractive index
1.755 – 1.787
Surface relief
High
Principal indices
nα 1.755 – 1.761 · nβ 1.772 – 1.786 · nγ 1.774 – 1.787
Birefringence
0.022
Pleochroism
Visible

nX = Blood-red nY = Light yellow nZ = Sea-green

Dispersion
r > v, distinct to strong
Extinction
X ^ c = 51°, Y = b
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 11.03 Å · b = 12.12 Å · c = 5.5 Å
Cell angles
β = 114.1 °
Ratio a:b:c
1 : 1.099 : 0.499
Z
2
Morphology

As terminated prisms elongated on [010] , or bladed and tabular on (100) , with many forms, yielding complex wedgelike terminations. In divergent or subparallel rosette-like aggregates, to 6 mm; may be in druses.

Type-locality form

Pink bladed crystals in groups

Comment

P21/c setting (P21/n setting also possible)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese754.938384.566
48.16%
8OOxygenOxygen1615.999255.984
32.06%
33AsArsenicArsenic274.922149.844
18.77%
1HHydrogenHydrogen81.0088.064
1.01%
Total798.458100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Allactiet
  • Allactit
  • Allactita
  • Allaktita
  • Allaktite
  • Allaktitt
  • Elfstorpite

In other languages

French
allactite
German
Allaktit
Spanish
Alactita
Italian
allactite · Allaktite · Elfstorpite
Arabic
ألاكتايت · ألاكتيت

Classification

Strunz
10th ed.

8.BE.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BEWith only medium-sized cations, (OH, etc.):RO4 > 2:1Group
  • 8.BE.30AllactiteSpecies
Dana
8th ed.

41.02.01.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.02(AB)7(XO4)2ZqType
  • 41.02.01Allactite GroupGroup
  • 41.02.01.01AllactiteSpecies
CIM

20.8.6

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.8Arsenates of MnGroup
  • 20.8.6AllactiteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1884Sjögren, H. (1884) Svenska Vetenskapsakademien, Stockholm, Öfv.: 41, no. 3: 29. [as Allaktit]
  2. 1884Sjögren, Anton (1884) Mineralogiska notiser VII. Allaktit, ett nytt manganarseniat från Mossgrufvan å Nordmarksfältet. Geologiska Föreningen i Stockholm Förhandlingar, 7 (2) 109-111 doi:10.1080/11035898409444127DOI: 10.1080/11035898409444127
  3. 1884Sjögren, Hj. (1884) Kristallografiska studier: VIII. Allaktit från Nordmarken. Geologiska Föreningen i Stockholm Förhandlingar, 7 (4) 220-236 doi:10.1080/11035898409443537DOI: 10.1080/11035898409443537
  4. 1885Sjögren, H. (1885) Ueber die Manganarseniate von Nordmarken in Wermland. Zeitschrift für Kristallographie: 10: 113-155.
  5. 1887Sjögren, H. (1887) Svenska Vetenskapsakademien, Stockholm, Öfv.: 44: 109 (Lundström analysis).
