Holtstamite

Ca3Al2(SiO4)2(OH)4
IMA status
  • Approved
IMA symbol
Hts
IMA approved
2003
Also known as
  • Holtstamiet
  • IMA2003-047

Where it forms, where it's found

Geological setting

Calc-silicate skarn.

Type locality
Wessels Mine
  1. Joe Morolong Local Municipality
  2. John Taolo Gaetsewe District Municipality
  3. Northern Cape
  4. South Africa

-27.1135°, 22.8544°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Brownish-yellow · pale-yellow · gray-white · white · colorless
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
3.33 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.718 – 1.746
Surface relief
High
Principal indices
nω 1.718 · nε 1.746
Birefringence
0.028
Pleochroism
Weak

O = pale orange yellow and E = lemon yellow.

Extinction
Parallel
Notes

Absorption: E > O.

Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#177
Cell parameters
a = 12.337 Å · c = 11.93 Å
Z
8
Twinning

Twinning around [111], creating pseudo-octahedrons.

Type-locality form

Rounded grains (up to 3 mm) composed of small (< 0.4 mm) commonly twinned crystals. Occasionally, the crystals make up pseudo-octahedra.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
45.03%
20CaCalciumCalcium340.078120.234
28.20%
14SiSiliconSilicon228.08556.170
13.17%
13AlAluminiumAluminium226.98253.964
12.66%
1HHydrogenHydrogen41.0084.032
0.94%
Total426.388100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Holtstamiet
  • IMA2003-047

In other languages

German
Holtstamit · IMA 2003-047
Italian
Holtstamite

Classification

Strunz
10th ed.

9.AD.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ADNesosilicates without additional anions; cations in [6] and/or greater coordinationGroup
  • 9.AD.25HoltstamiteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 2005Hålenius, Ulf, Häussermann, Ulrich, Harryson, Hans (2005) Holtstamite, Ca3(Al,Mn3+)2(SiO4)3-x(H4O4)x, a new tetragonal hydrogarnet from Wessels Mine, South Africa. European Journal of Mineralogy, 17 (2) 375-382 doi:10.1127/0935-1221/2005/0017-0375DOI: 10.1127/0935-1221/2005/0017-0375
  2. 2014(2014) Holtstamite. Handbook of Mineralogy. Mineralogical Society of America
