Hulsite

Fe2+2Fe3+O2(BO3)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hls
Discovered
1908
Also known as
  • Hulsiet

Where it forms, where it's found

Geological setting

Contact metamorphosed limestone.

Type locality
Brooks Mountain
  1. York Mountains
  2. Port Clarence Mining District
  3. Nome Census Area
  4. Alaska
  5. USA

65.5390°, -167.1305°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black with greenish · brownish · or reddish tinge
Streak
Black
Cleavage
Distinct/Good

good on (110)

Density
4.28 g/cm³

Optical

Optical type
Biaxial

Crystallography

Crystal system
Monoclinic
Space group
P2/m
Cell parameters
a = 10.695(4) Å · b = 3.102(1) Å · c = 5.431(1) Å
Cell angles
β = 94.21(3) °
Ratio a:b:c
1 : 0.290 : 0.508
Z
2
Morphology

Small, rectangular crystals. Faces uneven and dull. Tabular masses.

Twinning

On [001]. One member of the twinning rotated 120° relative to the other.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron355.845167.535
64.85%
8OOxygenOxygen515.99979.995
30.97%
5BBoronBoron110.81010.810
4.18%
Total258.340100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hulsiet

In other languages

German
Hulsit
Italian
Hulsite
Chinese
黑硼锡铁矿

Classification

Strunz
10th ed.

6.AB.45

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ABBO3, with additional anions; 1(D) + OH, etc.Group
  • 6.AB.45HulsiteSpecies
Dana
8th ed.

24.02.03.01

  • 24Anhydrous BoratesClass
  • 24.02A2BO2[XO3]Type
  • 24.02.03— unnamed intermediate level —Group
  • 24.02.03.01HulsiteSpecies
CIM

9.6.4

  • 9BoratesClass
  • 9.6Borates of Ti, Sn and TaGroup
  • 9.6.4HulsiteSpecies

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1908Knopf, A., Schaller, W.T. (1908) Two new boron minerals of contact-metamorphic origin. American Journal of Science: 175: 323-331
  2. 1910Schaller, W.T. (1910) Chemical composition of hulsite and paigeite. American Journal of Science: Series 4: 29: 543-549.
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1974Vlisidis, Angelina C.; Schaller, Waldemar T. (1974) The identity of paigeite with vonsenite, and chemical analyses of vonsenite, ludwigite, and hulsite. Neues Jahrbuch für Mineralogie - Monatshefte, 1974 (3-4). 95-105 doi:10.1127/njmm/1974/1974/95DOI: 10.1127/njmm/1974/1974/95
  5. 1976Konnert, Judith A., Appleman, Daniel E., Clark, Joan R., Finger, Larry W., Kato, Toshio, Miura, Yasunori (1976) Crystal structure and cation distribution of hulsite, a tin-iron borate. American Mineralogist, 61 (1-2) 116-122
