Hurlbutite

CaBe2(PO4)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hrb
Discovered
1951
Also known as
  • Cherlbutit
  • Cherlbutita
  • Cherlbutite
  • +2 more

Where it forms, where it's found

Geological setting

Complex granite pegmatite; observed as an alteration product of beryl.

Type locality
Chandlers Mill Quarry
  1. Newport
  2. Sullivan County
  3. New Hampshire
  4. USA

43.3578°, -72.2522°

14recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Greenish white · yellow or colourless
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
2.877 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70° · 2V calc = 70°
Refractive index
1.595 – 1.604
Surface relief
Moderate
Principal indices
nα 1.595 · nβ 1.601 · nγ 1.604
Dispersion
r > v, weak.
Extinction
X = b; Y = c; Z = a.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 8.299(1) Å · b = 8.782(2) Å · c = 7.798(3) Å
Cell angles
β = 90.5 °
Ratio a:b:c
1 : 1.058 : 0.940
Z
4
Morphology

Stout prismatic crystals, spheres with a radial fibrous structure. In the type material, forms c(001) and m(111) are dominant and are truncated by d(201) and b(010). On one crystal the form e(101) occurred as a very small face.

Type-locality form

Stout prismatic crystals to 25 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
51.60%
15PPhosphorusPhosphorus230.97461.948
24.97%
20CaCalciumCalcium140.07840.078
16.16%
4BeBerylliumBeryllium29.01218.024
7.27%
Total248.042100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cherlbutit
  • Cherlbutita
  • Cherlbutite
  • Hurlbutiet
  • Hurlbutite (of Mrose)

In other languages

German
Hurlbutit
Italian
Hurlbutite
Chinese
磷钙铍石

Classification

Strunz
10th ed.

8.AA.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.AAWith small cations (some also with larger ones)Group
  • 8.AA.15HurlbutiteSpecies
Dana
8th ed.

38.03.06.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.03(AB)3(XO4)2Type
  • 38.03.06— unnamed intermediate level —Group
  • 38.03.06.01HurlbutiteSpecies
CIM

19.3.3

  • 19PhosphatesClass
  • 19.3Phosphates of Be and MgGroup
  • 19.3.3HurlbutiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1952Mrose, Mary E. (1952) Hurlbutite, CaBe2(PO4)2, a new mineral. American Mineralogist, 37 (11-12) 931-940
  2. 1974Lindbloom, J. T., Gibbs, G. V., Ribbe, and P. H. (1974) The crystal structure of hurlbutite: A comparison with danburite and anorthite. American Mineralogist, 59 (11-12) 1267-1271
  3. 2005(2005) Hurlbutite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2014Dal Bo, Fabrice, Hatert, Frédéric, Baijot, Maxime (2014) Crystal chemistry of synthetic M2+Be2P2O8 (M2+ = Ca, Sr, Pb, Ba) beryllophosphates. The Canadian Mineralogist, 52 (2) 337-350 doi:10.3749/canmin.52.2.337DOI: 10.3749/canmin.52.2.337
  5. 2023Gorelova, L.A. (2023) Phase Transformations in Feldspar Group Minerals with Paracelsian Topology under High Temperature and High Pressure. Russian Geology and Geophysics, 64 (8). 950-961 doi:10.2113/rgg20234557DOI: 10.2113/rgg20234557
