Strontiohurlbutite

SrBe2(PO4)2
IMA status
  • Approved
IMA symbol
Shrb
Discovered
2012
IMA approved
2012
Also known as
  • IMA2012-032
  • Strontiohurlbutiet

Where it forms, where it's found

Geological setting

a highly evolved and well-zoned pegmatite

Type locality
Pegmatite No. 31
  1. Nanping pegmatite field
  2. Yanping District
  3. Nanping
  4. Fujian
  5. China

26.6572°, 118.1022°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
light blue
Tenacity
brittle
Cleavage
None Observed
Density
3.101 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 68.5° · 2V calc = 70°
Refractive index
1.563 – 1.572
Surface relief
Moderate
Principal indices
nα 1.563 · nβ 1.569 · nγ 1.572
Pleochroism
Non-pleochroic
Dispersion
weak dispersion, r > v,
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 8.426(5) Å · b = 8.998(5) Å · c = 8.005(4) Å
Cell angles
β = 90.05(5) °
Ratio a:b:c
1 : 1.068 : 0.950
Z
4
Type-locality form

platy, subhedral-to-anhedral, with a length from 5 mm to 1.5 mm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
43.30%
38SrStrontiumStrontium187.62087.620
29.64%
15PPhosphorusPhosphorus230.97461.948
20.96%
4BeBerylliumBeryllium29.01218.024
6.10%
Total295.584100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2012-032
  • Strontiohurlbutiet

In other languages

German
IMA 2012-032 · Strontiohurlbutit
Italian
strontiohurlbutite

Classification

Strunz
10th ed.

8.00

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.0— unnamed intermediate level —Division
  • 8.00— unnamed intermediate level —Group
  • 8.00StrontiohurlbutiteSpecies

Group, growth & confusion

Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 14. Mineralogical Magazine, 76 (5) 1281-1288 doi:10.1180/minmag.2012.076.5.15DOI: 10.1180/minmag.2012.076.5.15
  2. 2014Rao, C., Wang, R., Hatert, F., Gu, X., Ottolini, L., Hu, H., Dong, C., Dal Bo, F., Baijot, M. (2014) Strontiohurlbutite, SrBe2(PO4)2, a new mineral from Nanping No. 31 pegmatite, Fujian Province, Southeastern China. American Mineralogist, 99 (2) 494-499 doi:10.2138/am.2014.4547DOI: 10.2138/am.2014.4547
  3. 2014Dal Bo, Fabrice, Hatert, Frédéric, Baijot, Maxime (2014) Crystal chemistry of synthetic M2+Be2P2O8 (M2+ = Ca, Sr, Pb, Ba) beryllophosphates. The Canadian Mineralogist, 52 (2) 337-350 doi:10.3749/canmin.52.2.337DOI: 10.3749/canmin.52.2.337
  4. 2017(2017) Strontiohurlbutite. Handbook of Mineralogy. Mineralogical Society of America
