Iranite

CuPb10(CrO4)6(SiO4)2(OH)2
IMA status
  • Approved
IMA symbol
Irn
Discovered
1963
Also known as
  • Iraniet
  • Khuniite

Where it forms, where it's found

Geological setting

Oxidized zone of hydrothermal veins.

Type locality
Sebarz Mine (Sebraz Mine
  1. Sebarg Mine)
  2. Anarak District
  3. Nain County
  4. Isfahan Province
  5. Iran
11recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Saffron-yellow

Optical

Optical type
Biaxial · 2V measured = Very large°
Refractive index
2.25 – 2.5
Surface relief
Very high
Principal indices
nα 2.25 – 2.3 · nγ 2.4 – 2.5
Pleochroism
Visible

On (100): brownish-orange along the elongation, yellow-orange perpendicular to the elongation.

Dispersion
relatively strong
Extinction
Extinction 5° to the elongation.
Notes

One index of refraction was approximately 2.25-2.30, and another was 2.40-2.50.

Michel-Lévy diagramhighlighted lineδ = 0.1750
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1750 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1750 nm
Order4th order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.5416(4) Å · b = 11.3992(5) Å · c = 11.3992(4) Å
Cell angles
α = 120.472(2) ° · β = 92.470(2) ° · γ = 55.531(2) °
Ratio a:b:c
1 : 1.195 : 1.195
Z
1
Morphology

Type description: Prominant forms (100), (010), (011) and also visible (101), (001), (102).

Twinning

Common on (12_1)

Type-locality form

Crystals to 0.5 mm.

Comment

Cell parameters from Tang et al. (2007).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead10207.2002072.000
67.94%
8OOxygenOxygen3415.999543.966
17.84%
24CrChromiumChromium651.996311.976
10.23%
29CuCopperCopper163.54663.546
2.08%
14SiSiliconSilicon228.08556.170
1.84%
1HHydrogenHydrogen21.0082.016
0.07%
Total3049.674100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Zn

Synonyms

  • Iraniet
  • Khuniite

In other languages

German
Iranit
Spanish
Iranita
Italian
Iranite

Classification

Strunz
10th ed.

7.FC.15

  • 7SulfatesClass
  • 7.FChromatesDivision
  • 7.FCWith PO4, AsO4, SiO4Group
  • 7.FC.15IraniteSpecies
Dana
8th ed.

36.01.01.01

  • 36Compound ChromatesClass
  • 36.01MiscellaneousType
  • 36.01.01— unnamed intermediate level —Group
  • 36.01.01.01IraniteSpecies
CIM

27.2.8

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.2ChromatesGroup
  • 27.2.8IraniteSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
2 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1963Bariand, Pierre, Herpin, Paulette (1963) Une nouvelle espèce minérale : l'iranite, chromate hydraté de plomb. Bulletin de Minéralogie, 86 (2) 133-135 doi:10.3406/bulmi.1963.5633 DOI: 10.3406/bulmi.1963.5633
  2. 1963Fleischer, Michael (1963) New Mineral Names. American Mineralogist, 48 (11-12) 1413-1421
  3. 1970Adib, D., Ottemann, J. (1970) Some new lead oxide minerals and murdochite from T. Khuni Mine, Anarak, Iran. Mineralium Deposita, 5 (1) 86-93 doi:10.1007/bf00207007DOI: 10.1007/bf00207007
  4. 1976Fleischer, Michael, Pabst, Adolf, Mandarino, Joseph A., Chao, George Y., Cabri, Louis, J. (1976) New Mineral Names. American Mineralogist, 61 (1-2) 174-186
  5. 1980Cesbron, Fabien, Williams, Sydney A. (1980) Iranite˗hémihédrite, bellite, phoenicochroite, vauquelinite et fornacite : synthèse et nouvelles données. Bulletin de Minéralogie, 103 (5) 469-477 doi:10.3406/bulmi.1980.7409DOI: 10.3406/bulmi.1980.7409
