Itsiite

Ba2Ca(BSi2O7)2
IMA status
  • Approved
IMA symbol
Its
IMA approved
2013
Also known as
  • IMA2013-085
  • Itsiiet

Where it forms, where it's found

Geological setting

Ba-rich skarn deposit associated with a quartz monzonite. Itsiite found in low temperature, late-stage veins

Type locality
Trench 1
  1. Gun claim
  2. Wilson Lake
  3. Itsi Mountain
  4. Watson Lake mining district
  5. Yukon
  6. Canada

62.8458°, -130.0056°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless and light blue to medium greenish-blue
Streak
White
Tenacity
brittle
Cleavage
Perfect

on (001)

Fracture
Splintery
Density
3.644 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.619 – 1.623
Surface relief
Moderate
Principal indices
nω 1.623 · nε 1.619
Pleochroism
Non-pleochroic
UV response
non-fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I-4 2m
Cell parameters
a = 10.9515(5) Å · c = 10.3038(7) Å
Unit cell volume
1235.79 ų
Z
4
Morphology

Tetragonal plates flattened on (001) and exhibit the forms (001), (101), and (112); ; the forms (101) and (112) are generally striated.

Type-locality form

As intergrowths of tetragonal plates up to 1 mm across. Crystals of Itsiite are commonly heavily included with cerchiaraite-(Fe)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium2137.327274.654
40.83%
8OOxygenOxygen1415.999223.986
33.30%
14SiSiliconSilicon428.085112.340
16.70%
20CaCalciumCalcium140.07840.078
5.96%
5BBoronBoron210.81021.620
3.21%
Total672.678100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2013-085
  • Itsiiet

In other languages

German
IMA 2013-085 · Itsiit
Italian
itsiite

Classification

Strunz
10th ed.

9.CH.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CH[Si4O12]8- 4-membered double ringsGroup
  • 9.CH.05ItsiiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2013Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2013) New minerals and nomenclature modifications approved in 2013. CNMNC Newsletter No 18. Mineralogical Magazine, 77 (8) 3249-3258 doi:10.1180/minmag.2013.077.8.15DOI: 10.1180/minmag.2013.077.8.15
  2. 2014Kampf, Anthony R., Peterson, Ronald C., Joy, Brian R. (2014) Itsiite, Ba2Ca(BSi2O7)2, a new mineral species from Yukon, Canada: Description and crystal structure. The Canadian Mineralogist, 52 (3) 401-407 doi:10.3749/canmin.52.3.401 DOI: 10.3749/canmin.52.3.401
  3. 2015(2015) Itsiite. Handbook of Mineralogy. Mineralogical Society of America
