Kassite

CaTi2O4(OH)2
IMA status
  • Approved
IMA symbol
Kas
Discovered
1965
Also known as
  • Kassiet

Where it forms, where it's found

Geological setting

Miarolitic cavities of alkalic pegmatites.

Type locality
Afrikanda complex
  1. Murmansk Oblast
  2. Russia

67.4313°, 32.7556°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Brownish pink to pale yellow
Tenacity
very brittle
Cleavage
Perfect

Perfect on (010) and distinct on (101).

Density
3.42 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 58° · 2V calc = 62°
Refractive index
1.95 – 2.21
Surface relief
Very high
Principal indices
nα 1.95 · nβ 2.13 · nγ 2.21
Pleochroism
Weak

Colorless to pale yellow

Dispersion
very strong: r> v
Notes

X=c, Z=b

Michel-Lévy diagramhighlighted lineδ = 0.2600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2600 nm5th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2600 nm
Order5th order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 5.275(1) Å · b = 9.009(2) Å · c = 9.557(2) Å
Cell angles
β = 90.43 °
Ratio a:b:c
1 : 1.708 : 1.812
Z
4
Morphology

Flattened on (010), the predominant face. Smaller (181) and (270) and minor (251), (031) and (101).

Twinning

Twinning common on (101} and (181).

Type-locality form

Crystals on the walls of miarolitic cavities. Forms pseudomorphs after perovskite and replaces ilmentite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
41.06%
22TiTitaniumTitanium247.86795.734
40.94%
20CaCalciumCalcium140.07840.078
17.14%
1HHydrogenHydrogen21.0082.016
0.86%
Total233.822100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Kassiet

In other languages

French
Kassite
German
Kassit
Spanish
Kassita · Kassita (mineral)
Italian
Kassite
Russian
кассит

Classification

Strunz
10th ed.

4.DH.10

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DHWith large (+- medium-sized) cations; sheets of edge-sharing octahedraGroup
  • 4.DH.10KassiteSpecies
Dana
8th ed.

08.03.09.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.09— unnamed intermediate level —Group
  • 08.03.09.01KassiteSpecies
CIM

7.9.7

  • 7Oxides and HydroxidesClass
  • 7.9Oxides of TiGroup
  • 7.9.7KassiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1965Kukharenko, A.A., Orlova, M.P., Bulakh, A.G., Bagdasarov, E.A., Rimskaya-Korsakova, O.M., Nefedov, Y.I., Ilyinskiy, G.A., Sergeyev, A.C., Abakumova, N.B. (1965) The Caledonian complex of the ultrabasic alkaline rocks and carbonatites of the Kola Peninsula and northern Karelia. Izdatelstvo "Nedra" Moskva: 1965: 368-375.
  2. 1967Fleischer, Michael (1967) New Mineral Names. American Mineralogist, 52 (3-4) 559-564
  3. 1968Association, International Mineralogical (1968) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 36 (284). 1143-1145 doi:10.1180/minmag.1968.036.284.11 DOI: 10.1180/minmag.1968.036.284.11
  4. 1969Fleischer, Michael (1969) New Mineral Names. American Mineralogist, 54 (1-2) 326-330
  5. 1986Evans, H.T. Jr., Dwornik, E.J., Milton, C. (1986) Kassite from the Diamond Jo quarry, Magnet Cove, Hot Spring County, Arkansas: The problem of cafetite and kassite. American Mineralogist: 71(7-8): 1045-1048.
